Schneider DO1130000 PLC Module

This output module provides eight discrete transistor outputs for Modicon M171 controllers. It switches DC loads directly from the PLC backplane without external relays. You can use this unit for solenoid, contactor, and indicator light control.

Technical Specifications

Parameter	Value
Model	Schneider DO1130000
Category	PLC Module
Number of Outputs	8 points
Output Type	Transistor sinking (NPN)
Output Voltage Range	12–24 VDC
Output Current per Point	0.5 Amps maximum
Maximum Load per Module	4 Amps total
Output Response Time	0.5 ms typical (ON), 1.0 ms typical (OFF)
Output Protection	Short-circuit and overtemperature
Isolation	1500 VAC optical (field to logic)
Internal Power Draw	150 mA from +5 VDC backplane
Dimensions (W x H x D)	3.2 cm × 9.5 cm × 7.0 cm
Weight	0.18 kg (0.40 lbs)
Connector Type	One 10-pin removable screw terminal
Component Count	1 main board + 8 MOSFETs + 8 optoisolators + 8 LEDs
Energy Storage	47 µF buffer capacitor
Operating Temperature	0°C to 55°C

Output Design and Switching

The Schneider DO1130000 uses eight N-channel MOSFETs for DC load switching. Each output connects between the load and DC common (sinking configuration). A 0.5 ms turn-on time provides fast response for high-speed applications. Red LEDs illuminate when their corresponding outputs energize.

Performance Characteristics

Each output handles 0.5 Amps of continuous DC current at 24 VDC. The total module load should not exceed 4 Amps across all eight points. Short-circuit protection automatically shuts down any overloaded output channel. Thermal shutdown activates if any MOSFET exceeds safe operating temperatures.

Isolation and Noise Immunity

Optical isolators separate each output channel from the internal logic side. This 1500 VAC rating prevents noise from corrupting the PLC backplane. The design eliminates ground loops between the controller and field devices. Consequently, the module performs reliably in electrically noisy industrial environments.

Installation and Wiring

Mount this module directly on DIN rail inside a small control panel. The 10-pin removable terminal block accepts wires from 18 to 24 AWG. For best results, use copper conductors rated for 75°C minimum. You should also install a suppression diode across each inductive load to protect the output transistor.

Compatibility and Application

This module fits Modicon M171 and M172 logic controller systems exclusively. It occupies a single slot in the controller expansion configuration. You can mix this unit with other DO or DM series modules freely. For best results, use SoMachine Basic software for module configuration.

Visual Status Indication

Eight red LEDs on the front panel show the real-time output status. Each LED illuminates when its corresponding transistor receives a turn-on signal. Therefore, technicians can verify output operation without a multimeter. A green LED indicates that the module has backplane power.

Energy Storage and Protection

A 47 µF capacitor maintains output logic during brief power interruptions. Each channel includes built-in overcurrent protection against short circuits. The module automatically restores output operation once the fault clears. This design protects both the module and your connected field devices from damage.

Why Choose This Module

This compact output module fits perfectly into space-limited small machine panels. Its fast 0.5 ms response suits high-speed packaging and labeling equipment. Therefore, this unit works well for conveyors, pick-and-place machines, and assembly fixtures.
