Schneider DBV 104 Ethernet TCP/IP Module

The Schneider DBV 104 Ethernet TCP/IP Module offers a reliable and high-speed solution for industrial networking and automation applications. Designed to seamlessly integrate into various control systems, it supports Ethernet communication over TCP/IP, ensuring fast and stable data transmission. Whether you’re building or expanding an industrial network, the DBV 104 provides robust performance to meet the demands of modern automation processes.

Key Features and Specifications

• Model Number: Schneider DBV 104
• Category: Ethernet TCP/IP Module
• Communication Protocol: TCP/IP
• Network Type: Ethernet
• Power Supply: 24V DC
• Operating Temperature: -10°C to 60°C
• Dimensions: 130mm x 110mm x 40mm
• Weight: 0.3 kg
• Interfaces: 1 x Ethernet port (RJ45), 2 x LEDs for status indicators
• Data Transmission Rate: 10/100 Mbps
• Mounting Type: DIN Rail Mount
• Bus Current Requirement: 100 mA

Product Overview

The Schneider DBV 104 Ethernet TCP/IP Module is engineered for optimal performance in industrial networking applications. It supports both 10 and 100 Mbps Ethernet speeds, providing reliable communication across industrial networks. This module is compatible with a wide range of control systems, enabling seamless data exchange between devices.

With a compact design of 130mm x 110mm x 40mm and a weight of just 0.3 kg, the DBV 104 is perfect for environments where space is limited. It operates on a 24V DC power supply, ensuring energy efficiency without sacrificing performance. The module’s operating temperature range of -10°C to 60°C makes it suitable for use in various industrial environments, from manufacturing to process control.

The DBV 104 Ethernet module features a single Ethernet port (RJ45), ensuring reliable connectivity for network communication. It also includes two status LEDs that display the operational status of the module for easy monitoring. Mounting the module is simple and convenient with its DIN rail mount feature, allowing for easy installation in control cabinets.

Applications

The Schneider DBV 104 Ethernet TCP/IP Module is ideal for industrial automation, process control, and manufacturing systems that require reliable and high-speed communication. It can be used in various industries, including automotive, energy, and manufacturing, providing a robust and scalable networking solution.

Product Details

• Brand: Schneider
• Model: DBV 104
• Category: Ethernet TCP/IP Module
