Schneider CAEP 108 I/O Communication Module

Efficient and Reliable Communication for Industrial Automation

The Schneider CAEP 108 I/O communication module is designed for seamless integration in industrial automation systems. Offering high performance and reliability, this module ensures smooth data transmission between I/O devices and control systems. It enables efficient communication, making it an essential component in modern industrial setups.

Technical Specifications for Schneider CAEP 108**

Specification	Details
Manufacturer	Schneider Electric
Product Type	I/O Communication Module
Part Number	CAEP 108
Product Line	Modicon
Weight	0.5 kg (1.1 lbs)
Dimensions (L x W x H)	100 x 120 x 60 mm
Communication Protocol	Modbus RTU/ASCII, EtherNet/IP
Operating Voltage	24 V DC
Power Consumption	2 W
Mounting Type	DIN Rail Mount
Environmental Protection	IP20 (Dust protection)
Operating Temperature	-10°C to +60°C
Storage Temperature	-20°C to +70°C
Input/Output Capacity	32 I/O Points (16 inputs, 16 outputs)
LED Indicators	Power, Communication, and Status Indicators
Response Time	< 10 ms for I/O communication
Compliance Standards	CE, UL, IEC 61131-2

Key Features and Benefits

Reliable Communication Protocols: The Schneider CAEP 108 supports Modbus RTU/ASCII and EtherNet/IP, ensuring compatibility with various industrial control systems.
Compact Design: Measuring just 100 x 120 x 60 mm and weighing only 0.5 kg, the module is compact yet powerful. It fits easily into control panels with minimal space requirements.
High I/O Capacity: The module supports 32 I/O points, with 16 inputs and 16 outputs, providing flexibility for a wide range of applications.
Efficient Power Use: Operating on a 24 V DC input with only 2 W power consumption, the module is energy-efficient for extended use.
Easy Installation and Mounting: The Schneider CAEP 108 features a DIN Rail mount, simplifying installation in industrial control panels.
Durable and Robust: With an IP20 protection rating, the module is designed for environments with minimal dust exposure. It operates efficiently in temperatures ranging from -10°C to +60°C, ensuring reliability even in demanding industrial settings.

Applications

The Schneider CAEP 108 I/O communication module is perfect for industrial automation applications where reliable communication is key. It is ideal for use in manufacturing, process control, and automation systems where data transmission efficiency is critical.

Conclusion

With its robust design, high I/O capacity, and wide compatibility, the Schneider CAEP 108 is a reliable solution for industrial communication needs. Whether you are upgrading an existing system or setting up a new one, this module delivers exceptional performance and ease of integration.
