The Schneider BIK 812 is a highly reliable Bitbus coupler interface module designed for seamless communication between devices in industrial automation systems. This module plays a vital role in connecting the Bitbus network to Schneider Electric controllers, providing fast, stable communication and enhancing system efficiency.
Key Features
- Manufacturer: Schneider Electric
- Model: BIK 812
- Product Type: Bitbus Coupler Interface Module
- Category: Industrial Automation
Technical Specifications
The Schneider BIK 812 interface module enables efficient data exchange and robust control capabilities in complex industrial networks. Here are the main technical details:
| Specification | Details |
|---|---|
| Module Type | Bitbus Coupler Interface Module |
| Part Number | BIK 812 |
| Product Line | Schneider Electric |
| Data Communication Protocol | Bitbus |
| Interface Type | Bitbus to Serial |
| Number of Connections | Up to 64 devices |
| Input Power | +5V DC (±5%) |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | -25°C to 85°C |
| Weight | 0.5 kg |
| Mounting Type | DIN Rail Mountable |
| Dimensions | 120 mm x 100 mm x 55 mm (L x W x H) |
| Max. Bitbus Transmission Speed | 500 Kbps |
Product Description
The Schneider BIK 812 acts as a Bitbus coupler interface module, providing vital functionality for industrial automation systems. It efficiently manages communication between controllers and devices on the Bitbus network, facilitating smooth data transfer.
Designed for easy installation, the BIK 812 mounts directly onto a DIN rail, reducing the need for additional infrastructure. It supports communication for up to 64 devices, ensuring seamless scalability. The 5V DC input power ensures that the module operates reliably in various environments, while the 0°C to 60°C operating temperature range ensures durability in industrial settings.
Benefits and Applications
- Seamless Communication: The ensures efficient communication across the Bitbus network.
- Scalability: With support for up to 64 devices, the module allows for flexible system expansion.
- Easy Installation: The DIN rail mounting feature simplifies setup and integration.
- Robust Performance: It operates within a 0°C to 60°C temperature range, making it suitable for industrial environments.
Conclusion
In conclusion, the Schneider is an essential Bitbus coupler interface module for any industrial automation system requiring reliable communication. With its high-speed data transmission, easy installation, and flexible scalability, it is the perfect solution for modern Schneider Electric applications.
