Schneider BIK 121 Automation Power Supply

Technical Overview of This Industrial Power Source

The Schneider BIK 121 delivers stable DC power to automation equipment. This power supply belongs to Schneider Electric’s legacy industrial component family. It converts AC mains voltage into regulated 24 V DC output. Consequently, your PLC and I/O modules receive clean operating power.

Hardware Specifications and Design Details

This power supply weighs approximately 0.8 kg. Its compact dimensions are 120 mm in height, 70 mm in width, and 100 mm in depth. The Schneider BIK 121 features a single-phase AC input interface. It uses a screw terminal block for line and neutral connections. The device contains one internal transformer and one rectifier circuit board. It stores minimal energy in its output capacitors for short-term hold-up. Therefore, the module maintains output for approximately 20 milliseconds during input dips.

Parameter	Specification
Manufacturer	Schneider Electric
Model	BIK 121
Category	Automation Power Supply
Input Voltage	85 V to 264 V AC (single-phase)
Output Voltage	24 V DC regulated
Output Current	1.2 A
Output Power	28.8 W
Weight	0.8 kg (1.76 lbs)
Dimensions (H x W x D)	120 x 70 x 100 mm
Interface	Screw terminal block (input and output)
Number of Components	Transformer, rectifier board, filter capacitors
Energy Storage	Output capacitors (20 ms hold-up time)
Mounting	DIN rail or panel
Efficiency	Approximately 85%

Installation and Operation Guidelines

You can mount the Schneider BIK 121 on a standard DIN rail. It connects directly to a single-phase mains supply. Furthermore, you should use an external circuit breaker for protection. The power supply provides short-circuit and overload protection internally. Always maintain adequate ventilation around this unit. This practice prevents overheating and extends product life.
