Schneider ASBDAP204 Output Module

The Schneider ASBDAP204 Output Module is a high-performance relay module from the DAP 204 Series. Designed to offer efficient output control in industrial automation, it features robust relay connections and versatile voltage support. This module provides reliable and consistent operation, even in challenging environments.

Key Features of the Schneider ASBDAP204 Output Module

4-Point Relay Configuration: The Schneider ASBDAP204 supports a 4-point relay setup, providing flexibility for various automation tasks.
Current Rating: Each relay point can handle 2 A, ensuring reliable switching for medium to high current loads.
Voltage Compatibility: The module supports 24-110 VDC and 24-230 VAC inputs, offering broad compatibility for different industrial applications.
Wide Operating Range: It operates efficiently across a wide voltage range, making it suitable for diverse power supply systems.
Durable Design: The ASBDAP204 is built to withstand harsh environments, providing long-term durability in industrial settings.
Compact Size: The module features a space-efficient design, perfect for integration into compact control panels.

Technical Specifications

Feature	Specification
Model	ASBDAP204
Type	Output Module (Relay)
Series	DAP 204 Series
Relay Configuration	4-Point Relay
Current Rating per Point	2 A
Voltage Compatibility	24-110 VDC / 24-230 VAC
Operating Temperature Range	-10°C to 55°C
Relay Type	SPDT (Single Pole Double Throw)
Mounting Type	DIN Rail Mountable
Dimensions	Compact Design
Environmental Protection	IP20 (dust protection)
Power Supply	External supply required for operation

Why Choose the Schneider ASBDAP204 Output Module?

The Schneider ASBDAP204 offers several key advantages for industrial applications:

Versatile Voltage Support: This module supports both DC and AC voltages (24-110 VDC / 24-230 VAC), making it adaptable to various industrial power systems.
High Switching Capacity: The 2A current rating per point ensures it can handle medium to high current switching reliably.
Durable and Reliable: With its IP20 protection and robust design, the ASBDAP204 is built to last, offering longevity in demanding automation environments.
Space-Efficient: Its compact design allows for easy integration into control panels without occupying excessive space.

Applications of the Schneider ASBDAP204 Output Module

The Schneider ASBDAP204 is ideal for use in the following applications:

Industrial Automation: It is perfect for controlling and switching various devices and equipment in industrial automation systems.
Factory Control Systems: This module offers excellent relay switching capabilities for factory control and monitoring systems.
Energy Management Systems: It is suitable for switching high-power loads in energy management and distribution systems.
Building Automation: Ideal for integrating into building control systems, including HVAC and lighting control.
