Schneider ASBDAO216 Output Module – 16 Points, 24V DC

The Schneider ASBDAO216 is a reliable output module from Schneider Electric’s Modicon series. With 16 output points and a 0.5 A current rating per output, this module operates at a standard 24 V DC voltage, making it ideal for various industrial automation applications. Additionally, it supports secure and easy connections through screw terminals, ensuring seamless integration into control systems.

Key Features

• Manufacturer: Schneider Electric
• Model: ASBDAO216
• Product Line: Modicon
• Product Type: Output Module
• Number of Output Points: 16
• Current Rating: 0.5 A per output
• Voltage Rating: 24 V DC
• Voltage Type: DC
• Electrical Connections: Screw terminals
• Weight: 0.94 lbs (0.43 kg)

Technical Specifications

Description

The Schneider ASBDAO216 is designed to offer efficient control and reliable performance for industrial automation systems. With its 16 output points, it supports a current rating of 0.5 A per output. This makes it suitable for many applications, especially those requiring 24 V DC direct current.

Moreover, the module’s electrical connections are secured through screw terminals, making installation fast and easy. The robust design of this module ensures a long-lasting and stable operation, making it a preferred choice in demanding environments.

Additionally, the module’s compact size (weighing only 0.43 kg) ensures that it fits easily into standard control panels, optimizing the use of space while maintaining high performance.

Why Choose the Schneider ASBDAO216?

• Reliable and Stable: Each output point is rated for 0.5 A, providing reliable power for various applications.
• Versatile: It operates with 24 V DC, offering compatibility with a wide range of control systems.
• Easy Integration: The screw terminal connections simplify installation and ensure secure connections.
• Compact Design: Despite its powerful capabilities, the module is lightweight and space-efficient.

Applications

The Schneider ASBDAO216 is ideal for various industrial applications, including:

• Industrial Automation: Perfect for systems requiring 16 outputs for controlling machinery and processes.
• Machine Control: Reliable for use in manufacturing systems, ensuring precise output control.
• Process Control: Ideal for process control systems where high reliability and stable performance are essential.
• Energy Management: Efficient for use in energy systems, optimizing output control at 24 V DC.

Why Schneider Electric?

Schneider Electric is a global leader in industrial automation and control systems. The ASBDAO216 is part of Schneider’s commitment to providing innovative, efficient, and reliable automation solutions. With a reputation for quality, Schneider Electric ensures that its products, including the ASBDAO216, meet the highest standards of performance and durability.
