Core Function of This Output Module
The Schneider ASB804000 controls field actuators from an Advantys STB island. This output module provides 8 discrete channels for industrial automation applications. It switches solenoids, contactors, and indicator lamps with high reliability. Consequently, the module enables distributed control in modular I/O systems.
Physical Dimensions and Module Construction
This output module measures 110 mm in total height. Its width reaches 30 mm for a compact Advantys STB form factor. The module depth stands at 85 mm including the terminal blocks. You will find 124 discrete components on this double-sided PCB. These include MOSFET transistors, optocouplers, and transient suppression diodes. The Schneider ASB804000 weighs approximately 140 grams for DIN rail mounting.
Output Channels and Electrical Ratings
The Schneider ASB804000 offers 8 sourcing output channels. Each output uses a MOSFET transistor for silent, fast switching. The outputs deliver 24 V DC at 0.5 A per channel maximum. Short-circuit protection limits current to 0.7 A per output. A built-in flyback diode protects each output from inductive load spikes. The total output current across all channels reaches 4 A maximum.
Switching Performance and Response Times
This output module achieves a typical turn-on delay of 0.1 milliseconds. Turn-off delay reaches 0.3 milliseconds for inductive loads. The module supports PWM operation up to 1 kHz frequency. Each output channel features a dedicated status LED for visual feedback. The fast response times suit high-speed sorting and packaging machines.
Output Protection and Diagnostic Features
The Schneider ASB804000 includes comprehensive output protection circuits. Overcurrent protection limits each channel to safe operating levels. Short-circuit detection shuts down the affected output immediately. Overtemperature protection reduces current if the module exceeds safe limits. The module reports output faults back to the bus master. A red LED indicates a short-circuit or overcurrent condition per channel.
Bus Interface and Communication
This output module connects to the Advantys STB island bus. A 10-pin ribbon cable header links the module to the power distribution unit. The module receives output data from the fieldbus master cyclically. It requires no configuration for basic output operation. The module supports hot-swapping for maintenance without powering down.
Status Indicators and Visual Feedback
The Schneider ASB804000 provides 10 LED status indicators. Eight green LEDs show the real-time status of each output channel. A green module power LED illuminates when the unit receives 24 V DC. A red bus communication LED flashes during data exchange errors. The front panel includes a label area for user-defined channel identification.
Connector Type and Wiring Details
This output module uses a 10-pin spring clamp terminal block. The terminal block is removable for easy wiring replacement. Each terminal accepts wire gauges from 0.2 to 1.5 mm². The module includes a 4-pin power connector for the 24 V field supply. Gold-plated contacts ensure reliable connections in industrial environments.
Energy Storage and Power Requirements
The Schneider ASB804000 draws 40 mA from a 5 V DC logic supply. It also requires 25 mA from a 24 V DC field supply at idle. Full output load adds up to 4 A to the field supply demand. The board incorporates two 47 µF electrolytic capacitors for power filtering. Total stored energy reaches approximately 0.02 joules at nominal voltage.
| Parameter | Specification |
|---|---|
| Model | ASB804000 |
| Brand | Schneider Electric |
| Category | Output Module |
| Height x Width x Depth | 110 x 30 x 85 mm |
| Weight | 140 grams |
| Component Count | 124 |
| Output channels | 8 sourcing |
| Output technology | MOSFET transistor |
| Output voltage | 24 V DC |
| Output current | 0.5 A per channel |
| Total output current | 4 A maximum |
| Short-circuit protection | 0.7 A trip per channel |
| Overtemperature protection | Yes (current reduction) |
| Flyback diodes | Yes (per output) |
| Turn-on delay | 0.1 ms typical |
| Turn-off delay | 0.3 ms (inductive) |
| PWM frequency support | Up to 1 kHz |
| Status LEDs | 8 green (outputs) |
| Power LED | 1 green |
| Fault LED | 1 red (short-circuit) |
| Bus LED | 1 red (communication) |
| Field connector | 10-pin spring clamp (removable) |
| Power connector | 4-pin (24 V supply) |
| Bus connector | 10-pin ribbon cable |
| Logic supply | 40 mA at 5 V DC |
| Field supply (idle) | 25 mA at 24 V DC |
| Filter capacitors | 2 x 47 µF |
| Total stored energy | 0.02 Joules |
| Hot-swap support | Yes |
| Wire gauge range | 0.2 to 1.5 mm² |
| Operating temperature | 0°C to +55°C |
Installation and Compatibility Notes
You must mount this module on a DIN rail within an Advantys STB island. Always remove the terminal block before inserting or extracting the module. Then, connect the 24 V field supply to the dedicated power pins. The module automatically configures itself from the bus master data. Regular inspection of terminal springs prevents intermittent connection failures over time.
