The Schneider ADU S9 is a robust and high-performance analog input module designed to offer precise and reliable data acquisition in various industrial automation applications. As part of the Schneider Electric family of products, the ADU S9 ensures seamless integration into complex control systems, optimizing the overall efficiency of automation processes.
Key Features
- Model: Schneider ADU S9
- Category: Analog Input Module
- Manufacturer: Schneider Electric
- Product Line: Schneider Automation
Technical Specifications
| Specification | Details |
|---|---|
| Input Type | Analog Input |
| Number of Inputs | 8 channels |
| Input Voltage Range | 0 to 10 VDC |
| Input Signal Type | Voltage |
| Resolution | 12-bit |
| Power Supply | 24 VDC |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions (HxWxD) | 4.6 x 5.3 x 2.1 inches (117 x 135 x 53 mm) |
| Weight | 0.8 kg (1.76 lbs) |
| Mounting Type | DIN Rail or Panel Mountable |
| Protection Class | IP20 |
| Communication Interface | Modbus RTU |
| Response Time | 50 ms |
| Status Indicators | LED (Power, Error) |
Reliable and Precise Data Acquisition
The Schneider ADU S9 analog input module provides exceptional accuracy with a 12-bit resolution, ideal for systems that require high-fidelity data. It supports 8 input channels, making it suitable for multiple sensor connections. With an input voltage range of 0 to 10 VDC, this module is flexible and adaptable to a variety of analog sensors.
Designed for Durability and Efficiency
Built for industrial environments, the ADU S9 operates within a wide temperature range of -20°C to 60°C, ensuring reliable performance even in extreme conditions. It features an IP20 protection class, which offers sufficient protection against dust and allows it to withstand challenging industrial conditions.
Easy Integration with Communication Systems
With Modbus RTU communication support, the Schneider ADU S9 ensures effortless integration into existing control networks. The module supports fast response times, with an impressive 50 ms processing speed, making it suitable for time-sensitive applications.
Why Choose the Schneider ADU S9?
The Schneider ADU S9 offers a powerful and flexible solution for industrial automation systems. Whether you need accurate voltage measurements, efficient data communication, or high reliability, this analog input module is designed to meet your needs. Its simple installation, wide operating range, and robust design make it an excellent choice for a variety of applications.
