Schneider 690MCI00001 Cable Module | Altivar Drive Interface

The 690MCI00001 provides a dedicated interface between Altivar drives and control systems. This Schneider Electric cable module simplifies wiring for variable speed drive installations. We engineered this unit to ensure reliable signal transmission in industrial automation networks.

Technical Specifications and Design Features

This cable module weighs approximately 0.25 kilograms. Its compact dimensions measure 85 millimeters in height, 45 millimeters in width, and 55 millimeters in depth. The unit features a durable plastic enclosure with integrated strain relief for cable connections.

Parameter	Specification
Manufacturer	Schneider Electric
Model	690MCI00001
Category	Cable Interface Module
Connector Type	RJ45 to screw terminal
Cable Length	0.5 meters (integrated)
Interface Type	Modbus serial communication
Supported Drives	Altivar 61, 71, 212, 312 series
Signal Isolation	1.5 kV optical isolation
Protection Rating	IP20
Operating Temperature	-10°C to 55°C
Dimensions (H x W x D)	85 mm x 45 mm x 55 mm
Weight	0.25 kg

Engineers will appreciate the integrated signal isolation within the 690MCI00001. This module provides 1.5 kilovolts of optical isolation between the drive and controller. Consequently, this feature protects sensitive control equipment from electrical noise and ground loops.

Furthermore, the interface design prioritizes simple field wiring. One end features an RJ45 connector for direct drive attachment. The opposite end offers a screw terminal block for connection to PLC or Modbus networks. This terminal block accepts wires from 0.2 to 1.5 mm².

Connectivity and System Integration

You can deploy this cable module across various Altivar drive platforms. The 690MCI00001 supports Altivar 61, 71, 212, and 312 series drives. This compatibility makes it a versatile solution for mixed drive installations. The module enables seamless Modbus communication between drives and controllers.

The unit consumes no external power, drawing all necessary energy from the communication signals. This passive design eliminates additional power supply requirements. For reference, other Modicon and Altivar components share this same communication architecture.

Installation and Reliability

This cable module arrives with a pre-attached 0.5-meter cable for immediate use. You can mount the unit on standard DIN rails or secure it with panel mounting screws. The 690MCI00001 includes diagnostic LEDs for communication activity and status monitoring. These indicators provide quick verification of proper network operation.
