Schneider 140NOE51100C Ethernet MMSE Module

High-Performance Ethernet Connectivity for Industrial Automation

The Schneider 140NOE51100C Ethernet MMSE module is designed to provide high-speed communication between control systems and networked devices. Ideal for industrial automation environments, this module ensures seamless data transfer, enhancing system performance and reliability.

Technical Specifications for Schneider 140NOE51100C**

Specification	Details
Manufacturer	Schneider Electric
Product Type	Ethernet MMSE Module
Part Number	140NOE51100C
Product Line	Modicon
Weight	0.70 kg (1.54 lbs)
Dimensions (L x W x H)	120 x 110 x 50 mm
Network Protocol	Ethernet/IP, Modbus TCP/IP
Communication Ports	2x RJ45 Ethernet Ports
Power Supply	24V DC
Power Consumption	2.5 W
Mounting Type	DIN Rail
Environmental Protection	IP20
Operating Temperature	-10°C to +60°C
Storage Temperature	-20°C to +70°C
Compliance	CE, UL
Maximum Data Rate	100 Mbps
Diagnostic Capabilities	Built-in LED indicators for status and faults
Compatibility	Compatible with Schneider Modicon platforms

Key Features and Benefits

Fast Data Transfer: The Schneider 140NOE51100C module supports Ethernet/IP and Modbus TCP/IP protocols. It ensures a fast data rate of 100 Mbps, ideal for time-sensitive applications.
Reliable Communication: Dual RJ45 Ethernet ports provide flexibility and redundancy for network connections, ensuring robust communication even in demanding environments.
Flexible Power Options: This module operates on a 24V DC power supply and consumes just 2.5 W, making it energy-efficient and easy to integrate into existing systems.
Compact and Durable Design: The Schneider 140NOE51100C has a compact design with 120 x 110 x 50 mm dimensions and an IP20 protection rating, making it well-suited for industrial control panels.
Broad Temperature Range: The module operates efficiently within a temperature range of -10°C to +60°C, ensuring reliable performance across various industrial conditions.
Easy Installation: The DIN rail mounting feature simplifies installation and integration, allowing quick setup and secure positioning within control panels.
LED Indicators for Diagnostics: The module includes built-in LED status indicators for quick fault detection and network status monitoring, enhancing system maintenance and uptime.

Applications

The Schneider 140NOE51100C Ethernet MMSE module is perfect for industrial applications requiring high-speed, reliable Ethernet communication. It integrates seamlessly with the Modicon platform, making it ideal for manufacturing automation, process control, and remote monitoring systems.

Conclusion

Designed for industrial environments, the Schneider 140NOE51100C Ethernet MMSE module offers high performance, easy installation, and reliable communication. With its fast data transfer, flexibility, and compatibility with Modicon platforms, this module is an excellent choice for enhancing industrial automation systems.
