Schneider 140NOC78000 DIO Network Module

The Schneider 140NOC78000 is a powerful Ethernet DIO network module designed for the Modicon Quantum platform. It supports high-speed communication and robust network connectivity for industrial automation systems. Ideal for real-time data exchange, this module supports redundancy, high-speed Ethernet communication, and advanced protocol management. With versatile compatibility, it ensures reliable performance in critical applications.

Key Features

Communication Port Protocol: Supports Modbus TCP for seamless communication.
Exchange Mode: Operates in full duplex for efficient data transmission.
Maximum Number of Connections: Handles up to 128 connections for large-scale systems.
Transmission Rate: Supports 10/100 Mbit’s for fast data transfer.
Redundancy: Offers hot standby redundant architecture for increased reliability.
Topology: Compatible with redundant ring and daisy chain loop configurations.
Web Server: Built-in web server for easy management and monitoring.
Embedded Ethernet Service: Supports CIP Explicit Messaging and CIP Implicit Messaging for real-time control.

Technical Specifications

Specification	Description
Product Compatibility	140CPU6xxxx
Communication Port Protocol	Modbus TCP
Exchange Mode	Full Duplex
Maximum Number of Connections	128
Transmission Rate	10/100 Mbit’s
Redundancy	Hot Standby Redundant Architecture
Topology	Redundant Ring, Daisy Chain Loop
Web Server	Embedded Web Server
Ethernet Service	CIP Explicit Messaging, CIP Implicit Messaging
Transmission Medium	Twisted Pair, 10BASE-T/100BASE-TX, RJ45 Connector
Power Supply	Via the power supply of the rack
Communication Services	FDR Server, NTP Time Synchronization, SNMP Agent
Additional Features	DHCP/BootP Server, Device Type Manager (DTM), Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP)

Performance and Applications

The Schneider 140NOC78000 is designed for industries that require high-speed, reliable Ethernet communication. With its 10/100 Mbit’s transmission rate, this module ensures fast and uninterrupted data exchange. The hot standby redundancy feature enhances system uptime by offering a backup in case of failures.

The module is compatible with multiple network topologies, including redundant ring and daisy chain loop, ensuring flexible system design. It supports CIP messaging and integrates seamlessly with other Modicon Quantum components.

Applications

Industrial Automation: Optimizes communication between control systems, I/O devices, and networked equipment.
Power Generation: Enhances control and monitoring systems for power plants.
Oil and Gas: Ideal for real-time process control and monitoring.
Manufacturing: Efficient for large-scale, high-speed data transmission in automated manufacturing environments.

Accessories

RJ45 Connector: Standard Ethernet connector for reliable network communication.
Twisted Pair Cable: Supports 10BASE-T/100BASE-TX transmission standards.
