Schneider 140DDO35300 | Discrete Output Module

Overview of the Schneider 140DDO35300 Discrete Output Module

The Schneider 140DDO35300 is an essential discrete output module from the Modicon Quantum series. Designed for efficient control, it features 32 channels, each capable of operating at a nominal 24V DC output voltage. The output voltage ranges from 19.2 to 30V DC, offering flexibility for various applications. Furthermore, it supports a maximum load of 4 Amps per group, with the entire module capable of handling 16 Amps in total.

This module operates with positive logic (source) and requires 2 output words for proper addressing within control systems. Thanks to its rack-mountable design, it integrates seamlessly into existing setups. Additionally, the 140DDO35300 works efficiently across a wide temperature range from 0°C to 60°C and withstands extreme storage conditions, ranging from -40°C to 85°C.

Key Features and Specifications

Description

The Schneider 140DDO35300 provides 32 discrete output channels, offering reliable performance in industrial applications. It operates at a nominal voltage of 24V DC, with a voltage range between 19.2V and 30V DC. This module uses positive logic (source), making it ideal for diverse control tasks. To integrate it into control systems, it requires 2 output words for addressing.

Additionally, the 140DDO35300 is divided into 4 groups of channels, each supporting up to 4 Amps, with a total module rating of 16 Amps. It allows for minimal leakage current, with a maximum of 0.4 mA at 30V. The module’s operating temperature range spans from 0°C to 60°C, and it can endure storage temperatures from -40°C to 85°C, making it suitable for various environments.

Moreover, the module’s rack-mountable design ensures straightforward installation in existing setups. It works efficiently in environments with non-condensing relative humidity levels of up to 95%. With a power dissipation of only 3W per channel, it ensures energy-efficient performance. The required bus current is 330 mA, which is optimal for its operation.

Key Benefits

• 32 Channels for Discrete Outputs: The module supports 32 channels to meet various control requirements.
• Voltage Range: Operates within a flexible voltage range of 19.2V to 30V DC.
• High Load Current Capacity: Each group supports up to 4 Amps, for a total of 16 Amps per module.
• Low Leakage Current: Maximum of 0.4 mA at 30V for reliable output control.
• Wide Temperature Range: Operates between 0°C to 60°C, and withstands storage temperatures from -40°C to 85°C.
• Easy Installation: Rack-mountable design simplifies integration.
• Energy-Efficient: Only 3W per channel of power dissipation ensures low energy consumption.
