Schneider 140DDI67300C Discrete Input Module

The Schneider 140DDI67300C is a highly reliable discrete input module designed for the Modicon Quantum series. It supports 24 inputs with voltage ranges from 88 V to 150 V, offering precise signal integration for industrial applications. This module is equipped with advanced features, including high isolation ratings and fast response times, ensuring seamless operation and optimal system performance.

Key Features of the Schneider 140DDI67300C

Voltage Range: The 140DDI67300C accepts input voltages from 88 V to 150 V, with an absolute maximum voltage of 156.25 V, including ripple. This broad range ensures compatibility with various industrial systems.
High Isolation: This module offers strong isolation characteristics with 2500 Vrms between the group and bus, as well as 700 Vrms between the group and local circuits. These ratings ensure safe and stable performance, even in electrically noisy environments.
Fast Response Time: With a response time of just 0.7 ms, the 140DDI67300C ensures quick transitions between input states, ensuring timely and accurate control of automation processes.
Current Consumption: The 140DDI67300C has a bus current requirement of 200 mA, making it energy-efficient and easy to integrate into a wide variety of control systems.
Local Signaling: The module features 24 green LEDs for input status indication, along with a red LED to indicate external faults and a green LED for bus communication status.

Technical Specifications

Specification	Details
Model	140DDI67300C
Product Line	Modicon Quantum
Input Channels	24
Input Voltage Range	88 V to 150 V
Absolute Maximum Voltage	156.25 V (including ripple)
Response Time	0.7 ms
Isolation Rating (Group to Bus)	2500 Vrms for 1 minute
Isolation Rating (Group to Local)	700 Vrms for 1 minute
Power Dissipation	1 W + (0.62 x number of points on)
Input Current	2.5 mA DC
Bus Current Requirement	200 mA
Local Signaling LEDs	24 green LEDs, 1 red LED, 1 green LED
Marking	CE
Module Format	Standard

Why Choose the Schneider 140DDI67300C?

Versatile Input Voltage Range: The 140DDI67300C supports a wide voltage range from 88 V to 150 V, making it adaptable to various industrial automation environments.
Efficient Power Management: The module’s low power dissipation of just 1 W + (0.62 x number of points on) ensures energy efficiency while maintaining optimal performance.
High Isolation for Safety: With strong isolation ratings of 2500 Vrms and 700 Vrms, the 140DDI67300C protects both the system and sensitive components from electrical noise and surges.
Quick Response: The module’s 0.7 ms response time ensures rapid input state transitions, crucial for high-speed industrial applications that require precise timing.
Clear Status Indication: The 24 green LEDs provide real-time input status feedback, while the red LED signals faults, and the green LED indicates active bus communication, simplifying system diagnostics.
