ProSoft MVI69E-MBS Enhanced Communication Module

Product Overview

The MVI69E-MBS is a Modbus Serial Enhanced Communication Module developed by ProSoft Technology for Allen-Bradley® CompactLogix® systems. This module enables seamless integration of Modbus RTU devices, supporting both Master and Slave configurations. It offers flexible communication with two serial ports and supports RS-232, RS-422, and RS-485 interfaces, making it ideal for a wide range of industrial applications.

The MVI69E-MBS comes with Add-on Profiles and Instructions to simplify configuration and reduce development time. These tools streamline commissioning and ensure smooth integration into existing systems. Whether you need to control remote devices or connect to existing Modbus RTU networks, the MVI69E-MBS provides a reliable and efficient solution.

Key Features

Flexible Communication: Supports RS-232, RS-422, and RS-485 interfaces for broad connectivity options.
Modbus Master/Slave: Enables Modbus RTU communication in both Master and Slave configurations.
High Data Rates: Offers baud rate support from 110 to 115.2 kbps, ensuring fast and efficient data exchange.
Easy Configuration: Comes with Add-on Profiles and Instructions for seamless setup with CompactLogix® systems.
Compact Design: Fits into a 1769 single-slot CompactLogix chassis, optimizing space and minimizing installation complexity.
Wide Temperature Range: Operates between 0°C to 60°C (32°F to 140°F) and can withstand storage temperatures from -40°C to 85°C (-40°F to 185°F).
Reliable and Robust: Built for industrial environments with support for 5% to 95% non-condensing humidity and vibration resistance.

Technical Specifications

Parameter	Details
Model	MVI69E-MBS
Manufacturer	ProSoft Technology
Product Type	Modbus Serial Enhanced Communication Module
Compatible Platforms	Allen-Bradley® CompactLogix® systems
Module Type	1769 Single-slot module
Serial Interfaces	RS-232, RS-422, RS-485
Baud Rate Range	110 to 115.2 kbps
Power Supply	5 VDC, 500 mA
Operating Temperature	0°C to 60°C (32°F to 140°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Relative Humidity	5% to 95% (non-condensing)
Module Dimensions	Standard 1769 module size
Configuration Tool	ProSoft Configuration Builder

Applications

The MVI69E-MBS is perfect for a variety of industrial automation applications, including:

Connecting Modbus RTU devices to CompactLogix® controllers for seamless data exchange.
Remote I/O and distributed systems where reliable communication is essential.
Process control systems, ensuring stable communication between devices over long distances.
Industrial automation, providing efficient and flexible communication with legacy Modbus devices.

With its versatile design and robust features, the MVI69E-MBS is the ideal choice for companies looking to integrate Modbus RTU communication into CompactLogix® systems.
