ProSoft MVI69-GSC ASCII Serial Interface Module

Overview

The ProSoft MVI69-GSC Generic ASCII Serial Interface Module is designed to simplify adding two fully configurable ASCII communication ports to the CompactLogix and MicroLogix platforms. It enables seamless ASCII communication without occupying processor front ports or consuming valuable processing time. This module efficiently handles communication between ASCII-supporting devices and the CompactLogix/MicroLogix system, ensuring smooth data transfer.

Key Features

Two Configurable ASCII Ports: The MVI69-GSC provides two ports for sending and receiving large ASCII character strings, offering high communication flexibility.
Easy Integration: This module integrates ASCII-supporting devices into the CompactLogix or MicroLogix platform using ladder logic for simple setup and operation.
Minimal Processor Load: By offloading ASCII communication to the module, it ensures processor resources are freed up for other tasks.

Hardware Specifications

Specification	Details
Model	MVI69-GSC
Dimensions	Standard 1769 single-slot module
Current Load	800 mA max at 5VDC
Operating Temperature	0°C to 60°C (32°F to 140°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Relative Humidity	5% to 95% (non-condensing)

Connectors and Indicators

LED Indicators:
- Battery and Module Status
- Application Status
- Serial Port Activity
- CFG Port Activity
CFG Port:
- RJ45 (DB-9F with supplied cable)
- RS-232 only, no hardware handshaking
App Ports (P1, P2):
- Selectable between RS-232, RS-485, or RS-422 using a jumper
- RJ45 (DB-9F with supplied cable)
- RS-232 handshaking configurable
Optical Isolation:
- 500V isolation from backplane

Included with Unit

Cables:
- RJ45 to DB-9M for each port
Configuration Cable:
- 6-foot RS-232 cable

Applications

The MVI69-GSC is ideal for a wide range of industrial applications where efficient ASCII communication is required. It can be used to connect various ASCII-supporting devices to CompactLogix or MicroLogix platforms in industries such as:
