ProSoft MVI56E-MNET Modbus TCP/IP Client/Server Enhanced Network Interface Module

Overview

The ProSoft MVI56E-MNET is a Modbus TCP/IP Client/Server Enhanced Network Interface Module developed by ProSoft Technology. Specifically designed for Allen-Bradley ControlLogix systems, this module enables seamless communication over a TCP/IP network. By supporting both client and server modes, it ensures versatile operation for various industrial communication needs.

Key Features

• Flexible Communication: The module supports both Modbus TCP/IP client and server functions. This provides seamless integration with other systems and devices.
• Backward Compatibility: MVI56E-MNET remains fully compatible with earlier versions, simplifying migration. Consequently, users do not need to revise Ladder Logic or configurations.
• Fast Data Exchange: With 10/100 Mbps Ethernet connectivity, this module ensures high-speed communication for time-sensitive applications.
• Remote Configuration & Diagnostics: Through CIP Connect, users can access remote configuration and diagnostics, making it easier to monitor and manage networks.
• Compact Design: This single-slot module fits neatly into the ControlLogix chassis, simplifying installation and setup.
• Advanced Diagnostics: The 4-character alphanumeric LED display offers quick access to status messages, alarms, and network communication status.

Technical Specifications

Product Description

The ProSoft MVI56E-MNET offers an efficient solution for Modbus TCP/IP communication, allowing ControlLogix processors to function as either Modbus clients or Modbus servers. By supporting both client and server modes, it allows seamless integration with Modbus TCP/IP networks. The module can handle up to 5,000 words of user-definable data, providing flexibility for industrial automation.

Thanks to its backward compatibility, upgrading to the MVI56E-MNET is a straightforward process. No significant changes are needed for existing Relay Ladder Logic or configurations, making migration effortless. Moreover, the module supports CIP Connect, allowing users to access remote configuration and diagnostics across various networks like Ethernet/IP and ControlNet.

Built for reliability, the MVI56E-MNET withstands 30 g of operational shock and 50 g non-operational shock. It also performs reliably under 5 g vibration across a frequency range of 10 to 150 Hz. Operating within a temperature range of 0°C to 60°C (32°F to 140°F), this module is ideal for demanding industrial environments.

Additionally, the MVI56E-MNET features a 4-character LED display that provides diagnostic information, including status updates and alarm data. This ensures easy monitoring and troubleshooting during operation.

Battery Backup and Reliability

A Lithium Vanadium Pentoxide battery provides backup power to the real-time clock and CMOS memory. With a fully charged battery, the MVI56E-MNET can maintain backup power for up to 21 days. This ensures the module continues functioning even during temporary power losses.

Application Areas

The ProSoft MVI56E-MNET is suitable for a wide range of industrial applications, particularly where reliable network communication is crucial:

• Manufacturing Automation
• Process Control Systems
• Energy Management Systems
• Food and Beverage Production

Installation Guidelines

To ensure a smooth installation, follow these steps:

1. Power off the system to avoid electrical hazards.
2. Insert the MVI56E-MNET module into a compatible ControlLogix rack (single-slot).
3. Connect the Ethernet cable to the RJ45 port for network communication.
4. Utilize the LED diagnostic display to confirm the system status and troubleshoot if necessary.
