ProSoft MVI56-PDPS PROFIBUS DP I/O Slave Network Interface Module

Overview

The ProSoft MVI56-PDPS is a high-performance PROFIBUS DP I/O Slave Network Interface Module specifically designed for Allen-Bradley ControlLogix processors. This module enables seamless integration between PROFIBUS DP networks and ControlLogix systems, making it ideal for industrial automation applications that require efficient and reliable communication. With support for high-speed data transfer and flexible configuration options, the MVI56-PDPS simplifies PROFIBUS integration while offering excellent performance.

Key Features

• PROFIBUS DP Slave Functionality: The MVI56-PDPS functions as a PROFIBUS DP Slave, facilitating reliable communication between ControlLogix processors and PROFIBUS devices.
• High-Speed Communication: Supports baud rates of up to 12 Mbps, ensuring rapid data exchange between connected devices.
• Flexible Node Addressing: The PROFIBUS node address range is configurable from 0 to 125, providing flexibility for large network configurations.
• Ladder Logic Data Transfer: Data transfer is managed via Ladder Logic, ensuring precise control over the exchange between the module and connected devices.
• Configurable Data Mapping: Offers user-configurable data mapping, allowing flexible integration into various industrial applications.
• Serial Port for Configuration/Debugging: The module includes a serial port for easy configuration, monitoring, and troubleshooting.

Technical Specifications

Applications

The ProSoft MVI56-PDPS is ideal for various industries, including:

• Manufacturing Automation
• Process Control
• Energy Management
• Water/Wastewater Systems
• Oil & Gas
• Building Automation

This module allows seamless integration of PROFIBUS networks with Allen-Bradley ControlLogix systems, providing reliable and flexible communication in industrial environments.

Product Model, Manufacturer, and Category

• Brand: ProSoft
• Model: MVI56-PDPS
• Category: PROFIBUS DP Slave Network Interface Module
