Ovation 5X00109G02 High Performance Analog Input Module

The 5X00109G02 is a high-performance Analog Input Module, designed specifically for Emerson’s Ovation Distributed Control System (DCS). It supports 8 channels of analog inputs with HART communication, providing accurate and reliable signal acquisition. This module ensures optimal performance for critical industrial processes, offering robust signal processing capabilities.

Key Features and Specifications

The 5X00109G02 delivers superior performance, ensuring seamless data transfer and system integration. It is highly accurate and designed to function in demanding industrial environments. Below are the detailed specifications of the module:

Module Type: Analog Input Module (8 channels)
Manufacturer: Emerson
System Compatibility: Ovation Distributed Control System (DCS)
Signal Type: 4-20 mA, voltage signals
Communication Protocol: HART (Highway Addressable Remote Transducer)
Channels: 8 input channels for high-precision analog signals
Input Range: ±10V, 4-20mA
Resolution: 16-bit resolution
Accuracy: 0.1% of full scale
Power Supply: 24 VDC (Ovation DCS powered)
Dimensions: 150 x 120 x 30 mm (L x W x H)
Weight: 0.6 kg
Operating Temperature: -40°C to +70°C
Humidity: 5% to 95% (non-condensing)
Vibration Resistance: 5g, 10 Hz to 500 Hz
Shock Resistance: 10g, 20 milliseconds
Mounting Type: Rack-mountable or panel-mountable

Detailed Technical Specifications

Parameter	Specification
Module Type	Analog Input Module
Manufacturer	Emerson
System Compatibility	Ovation DCS
Signal Type	4-20 mA, Voltage
Channels	8 Channels (High-Performance)
Communication Protocol	HART (Highway Addressable Remote Transducer)
Input Range	±10V, 4-20mA
Resolution	16-bit resolution
Accuracy	0.1% of full scale
Power Supply	24 VDC
Dimensions	150 x 120 x 30 mm
Weight	0.6 kg
Operating Temperature	-40°C to +70°C
Humidity	5% to 95% (non-condensing)
Vibration Resistance	5g, 10 Hz to 500 Hz
Shock Resistance	10g, 20 milliseconds
Mounting Type	Rack-mountable or panel-mountable

Applications and Use Cases

The 5X00109G02 Analog Input Module offers versatility across various industrial automation applications. It is ideal for:

Industrial Process Control: It helps monitor and control vital processes in industries like power generation, water treatment, and manufacturing.
Data Acquisition: Its high-resolution inputs guarantee precise data collection, which enhances overall system performance and optimization.
Automation Systems: The 5X00109G02 integrates seamlessly with Ovation DCS, ensuring smooth control over complex systems.
HART Communication Devices: This module provides enhanced flexibility, allowing integration with a variety of field devices via HART protocol.

Moreover, this Analog Input Module ensures continuous and accurate performance, making it essential for mission-critical applications. It offers reliable signal processing even in harsh environments, which is crucial for industrial automation systems.

Where to Purchase

You can purchase the 5X00109G02 Analog Input Module from authorized Emerson Ovation DCS distributors. It is a key component for industrial systems, ensuring reliable signal input and seamless integration for optimal system performance.
