ICS Triplex T8870 – High Voltage Isolation Module

Overview

The ICS Triplex T8870 offers superior voltage isolation and low power consumption, making it ideal for industrial automation systems. It features robust isolation between power groups and field common, ensuring enhanced system safety and reliability. Moreover, this module operates efficiently across a wide temperature range, offering a compact design that suits various installation environments.

Designed for critical applications, the T8870 excels in environments where high reliability and consistent performance are essential. It can seamlessly integrate into systems that demand stability, even in challenging conditions.

Key Features

Voltage Isolation: Effectively isolates power groups and field common, ensuring the safety of connected systems.
Low Power Consumption: With only 0.3W per power group, it helps reduce energy costs while maintaining performance.
Compact and Lightweight: Its small form factor allows for integration in tight spaces without compromising on reliability.
Wide Operating Temperature: The module functions optimally between 0°C to 60°C, ensuring versatility in different environments.
Reliable Operation: Designed for industrial applications where continuous, uninterrupted performance is crucial.

Technical Specifications

Parameter	Specification
Field Supply Voltage	90-140 VDC
Power Dissipation	0.3W per power group
Isolation	Power Group to Power Group: 250V Basic (fault), 150V Reinforced (continuous)
	Field Common: 250V Basic (fault)
	Channel to Channel (within Power Group): None
Fusing	N/A
Operating Temperature	0°C to 60°C (32°F to 140°F)
Storage Temperature	-25°C to 70°C (-13°F to 158°F)
Relative Humidity	10% to 95%, non-condensing
Dimensions (L x W x H)	360 mm x 68 mm x 110 mm (14.17″ x 2.68″ x 4.33″)
Weight	950 g (2.1 lbs)

Country of Origin

Manufactured in: United States

Applications

The ICS Triplex T8870 is ideal for a broad range of industrial applications, including:

Industrial Control Systems: It ensures safe and reliable voltage isolation within control systems.
Power Distribution Systems: Provides reliable isolation for high-voltage systems, protecting the integrity of the entire system.
Automation Equipment: Suited for automation systems that require dependable operation in various environmental conditions.
Environmental Control Systems: Ensures consistent performance in demanding conditions that affect critical processes.

Why Choose the ICS Triplex T8870?

If your industrial system demands high-voltage isolation with low power consumption, the ICS Triplex T8870 is the perfect solution. Designed for performance, efficiency, and safety, this module guarantees long-term reliability, making it a valuable asset for any industrial control system.
