ICS Triplex T8442 | Field Power Supply Module

Overview

The ICS Triplex T8442 is a field power supply module designed for high-performance industrial applications. It provides reliable input and output specifications, ensuring the stability and efficiency of industrial automation systems. This module supports a wide range of input and output voltages and current, making it ideal for critical operations in demanding environments.

Key Features

Wide Input Voltage Range: The T8442 supports input voltages between 18 V DC and 32 V DC, ensuring compatibility with various industrial power sources.
Reliable Output Voltage: It delivers a stable 22.6 V DC output at a 50 mA load when operating at 24 V DC input voltage.
Flexible Input Specifications: The module includes open collector inputs and provides flexibility for integration into complex systems.
High-Performance Current Handling: It supports 1 A maximum input current for Vfield (A) and Vfield (B) inputs, ensuring efficient power management.
Compact and Lightweight: With its compact design, the T8442 offers efficient space utilization while maintaining durability.

Technical Specifications

Parameter	Details
Model	T8442
Category	Field Power Supply Module
Vfield Input Voltage Range	18 V DC to 32 V DC
Vfield Input Current	1 A max
Vfield Output Voltage (at 50 mA)	22.6 V DC (at 24 V DC input voltage)
Vfield Output Current	62.5 mA max
Open Collector Input Voltage	33 V max
Open Collector Output Resistance	4990 Ω
Bias Voltage Output	1.90 V DC (with 24 V DC input)
Differential Input Resistance	632 Ω (Passive inputs)
Differential Input Voltage	10 V max (at 632 Ω input resistance)
Dimensions (L x W x H)	391 mm x 127 mm x 102 mm
Weight	0.75 kg (1.6 lb)

Applications

The ICS Triplex T8442 is ideal for the following applications:

Industrial Automation Systems
Control Panels
Process Control Equipment
Field Devices and Sensors
Energy Management Systems

Benefits

High Input/Output Flexibility: The wide input and output voltage ranges provide compatibility with a variety of power sources and automation setups.
Compact and Durable: Designed to withstand harsh industrial environments, offering long-term reliability and minimal maintenance.
Efficient Power Distribution: Supports reliable current handling with precise output voltage, ensuring optimal system performance.
Easy Integration: The module’s open collector inputs and flexible resistance make it easy to integrate into existing automation and control systems.
