ICS Triplex T8433 Trusted TMR 24 VDC Analog Output Module

Overview

The ICS Triplex T8433 is a highly reliable Trusted TMR (Triple Modular Redundant) 24 VDC analog output module, specifically designed for critical industrial applications. With its advanced TMR architecture, the module ensures continuous operation, even if one of its channels fails. It provides three independent channels of analog output, each with its own processor and memory, ensuring superior fault tolerance and system reliability.

Key Features

Triple-Redundant Architecture: The ICS Triplex T8433 utilizes TMR to guarantee high availability and reliability in mission-critical environments.
24 VDC Analog Output: This module supports a 24 VDC analog output range, making it suitable for various industrial applications.
16-Bit Resolution: Provides highly accurate and precise analog output with 16-bit resolution.
0.05% Accuracy: Delivers exceptional output accuracy to ensure precise control and measurement.
100 Hz Sampling Rate: Fast data processing with a 100 Hz sampling rate ensures timely response and control.
Hot-Swappable Modules: Easily replace modules without interrupting system operation for enhanced uptime.
Built-in Diagnostics: Self-diagnostics continuously monitor the module’s health and operational status.
Multiple Communication Protocols: Supports Ethernet, Modbus, and Profibus protocols, enabling seamless integration with various systems.

Specifications

Parameter	Details
Channels	20 independent 4-20 mA inputs
Redundancy	Triple Modular Redundancy (TMR)
Output	4-20 mA analog output per channel
Resolution	16-bit
Accuracy	0.05%
Sampling Rate	100 Hz
Isolation	Galvanic isolation from system ground and other channels
Conformal Coating	Protects against moisture and contaminants
Impulse Withstand	2500 V
Diagnostic Resolution	1 ms for precise event tracking
Diagnostics	Automatic self-test and diagnostics
Hot-Replace Capability	Online replacement with Companion Slot or SmartSlot
LED Indicators	For input and module status
Certification	IEC 61508 SIL 3 for safety in critical systems
Operating Temperature	-25°C to +60°C (-13°F to 140°F)
Storage Temperature	-40°C to +85°C (-40°F to 185°F)
Weight	320g (0.7 lb)
Dimensions (L x W x H)	150 mm x 100 mm x 40 mm

Benefits

Uninterrupted Operation: The ICS Triplex T8433 provides high reliability and fault tolerance, crucial for safety-critical industrial systems.
Enhanced Accuracy and Precision: With a 16-bit resolution and 0.05% accuracy, the module ensures precise and reliable analog outputs.
Flexible Integration: Supports multiple communication protocols, making it versatile for various industrial automation setups.
Quick Maintenance: Hot-swappable capability reduces downtime during maintenance or module replacement.
Comprehensive Diagnostics: Continuous self-testing and built-in diagnostics help detect issues early, improving system uptime and performance.
