ICS Triplex T8314C Trusted Fibre Transmitter/Receiver Unit

Overview

The ICS Triplex T8314C is a high-performance Trusted Fibre Transmitter/Receiver (Tx/Rx) unit engineered to extend the Trusted Expander Bus over distances up to 10 kilometers. It ensures reliable data communication for demanding industrial applications, including process control, automation, and remote monitoring. The module combines rugged design, low power consumption, and dual power redundancy, providing uninterrupted operation in harsh industrial environments. Engineers can easily integrate it into existing control systems, improving overall system reliability and communication efficiency.

Key Features

Extends the Trusted Expander Bus reliably up to 10 km for long-distance industrial communication.
Dual 24 Vdc diode ORed power supply ensures continuous operation even if one power source fails.
Low power consumption reduces operational costs and supports energy-efficient installations.
Ruggedized design withstands high vibration, temperature variations, and industrial contaminants.
Quick DIN rail mounting allows fast installation without special tools.
User-friendly configuration simplifies integration and minimizes system downtime.
Supports high-speed, low-latency fibre communication for critical industrial processes.
Monitors link integrity and provides diagnostic feedback to prevent communication failures.

Technical Specifications

Parameter	Specification
Model Number	T8314C
Series	Trusted Fibre Transmitter/Receiver (Tx/Rx) Unit
Transmission Distance	Up to 10 km
Power Supply	Dual 24 Vdc diode ORed
Power Consumption	Low, optimized for industrial systems
Mounting	DIN rail mounting
Design	Ruggedized, industrial-grade construction
Operating Temperature Range	-40°C to +70°C
Weight	0.65 kg (1.43 lb)
Dimensions	180 mm x 90 mm x 40 mm (7.09 in x 3.54 in x 1.57 in)
Diagnostic Features	Link integrity monitoring, fault detection alerts
Compatibility	Fully compatible with ICS Triplex Trusted Expander Bus systems

Applications

Provides long-distance communication for industrial automation and control systems.
Ideal for power plants, refineries, and process industries requiring reliable data transfer.
Enables remote monitoring and control in distributed industrial networks.
Enhances communication redundancy, preventing system downtime during critical operations.
Supports high-speed data transfer for safety, security, and process monitoring applications.
