ICS Triplex T8200 Trusted Power Supply System

Overview

The ICS Triplex T8200 Trusted Power Supply System is designed for high-availability and critical applications where power reliability is essential. This triple-redundant system ensures continuous operation, even if one power supply fails. With three independent power supplies, each equipped with its own input and output circuits, the T8200 delivers exceptional redundancy and minimizes the risk of downtime in mission-critical operations.

Key Features

Triple-Redundant Power Supply: Ensures that the system remains operational even if one power supply fails.
Current Sharing: Balanced load distribution between power supplies enhances system performance and reliability.
Power Factor Correction: Improves energy efficiency and reduces electrical consumption.
Diagnostic Contacts: Monitors and reports the status of the power supply system for proactive maintenance.
Independent Input and Output Circuits: Each power supply operates independently, further enhancing system reliability.
High Availability: Designed to meet the needs of industries requiring continuous, uninterrupted power.

Technical Specifications

Specification	Details
Model	ICS Triplex T8200
Manufacturer	ICS Triplex
Power Supply Redundancy	Triple-redundant
Input Voltage	24 VDC nominal
Output Voltage	24 VDC nominal
Current Sharing	Yes, ensures balanced load distribution
Power Factor Correction	Yes, improves overall energy efficiency
Diagnostic Contacts	Yes, for status monitoring and system alerts
Weight	2.5 kg (5.5 lbs)
Operating Temperature	0°C to 60°C (32°F to 140°F)
Storage Temperature	-40°C to +85°C (-40°F to 185°F)
Operating Humidity	5% to 95%, non-condensing
Dimensions (L x W x H)	19.0 x 12.0 x 4.0 cm (7.48 x 4.72 x 1.57 inches)
Vibration	10 to 55 Hz, 0.15 mm peak
Shock Resistance	15 g, 11 ms half sine wave

Product Description

The ICS Triplex T8200 is a highly reliable power supply system built for critical environments. With its triple-redundant design, the T8200 guarantees continuous power even in the event of a failure in one of its power supplies. Each power supply operates independently, with its own input and output circuits, adding another layer of security for uninterrupted power delivery.

Additionally, the system features current sharing between power supplies to ensure optimal load distribution, enhancing both performance and reliability. The power factor correction feature helps improve efficiency, reducing electrical consumption and operational costs. The diagnostic contacts provide real-time monitoring of the power supply status, enabling early detection of potential issues and minimizing the risk of unexpected downtime.

This power supply system is designed to withstand a wide range of temperatures and environmental conditions, making it suitable for diverse industrial applications where reliability and uptime are non-negotiable.

Typical Applications

The ICS Triplex T8200 is ideal for industries that require uninterrupted power, including:

Oil & Gas: Ensuring reliable power for offshore platforms and onshore refineries.
Manufacturing: Powering critical machinery and systems in factories.
Energy: Providing backup power for turbines, generators, and other essential equipment.
Telecommunications: Ensuring continuous operation of communication networks.
Data Centers: Supporting mission-critical IT infrastructure with reliable power delivery.

Benefits

Using the ICS Triplex T8200 provides several key advantages:

Uninterrupted Power Supply: Redundant design ensures continuous operation, even in case of failure.
Improved Efficiency: Power factor correction reduces energy consumption and lowers operational costs.
Proactive Monitoring: Diagnostic contacts alert you to system status, enabling proactive maintenance.
Reliable and Robust: Designed for critical applications where downtime is not an option, ensuring maximum uptime and safety.
