Technical Overview
The Honeywell CC-TAIN11 is a high-performance digital input module designed for the Experion PKS Series C I/O platform and C300 controller systems . This module acquires discrete signals from field devices such as limit switches, proximity sensors, and pushbuttons, and transmits them to the controller for process monitoring and logic execution . It supports 32 sink-type (open drain) input channels, each capable of accepting 24 VDC signals with a typical response time under 5 ms . The robust industrial-grade construction includes conformal coating for enhanced protection against moisture, dust, and corrosive gases, ensuring reliable operation in harsh environments . Its 250 Ω input impedance ensures compatibility with a wide range of field devices .
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Model Number | CC-TAIN11 |
| Part Number | 51306515-175 |
| Product Type | Digital Input Module |
| System Compatibility | Experion PKS Series C, C300 Controller |
| Input Channels | 32 |
| Input Type | Sink (open drain) |
| Input Voltage | 24 VDC nominal (19-30 VDC range) |
| Input Impedance | 250 Ω |
| Response Time | ≤5 ms |
| Resolution | 12-bit |
| Sampling Rate | Up to 100 samples per second |
| Accuracy | ±0.1% of full scale (voltage), ±0.2% (current) |
| Power Supply | 24 VDC, 100 mA maximum |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | 155 x 127 x 58 mm |
| Weight | 0.5 kg |
| Mounting | Series C IOTA baseplate |
| Certifications | CE, UL, RoHS |
| Country of Origin | USA |
Key Features
High Channel Density – The 32-channel design provides extensive input capacity in a single slot, saving valuable rack space and reducing system costs.
Hot-Swap Capability – The module supports online replacement without powering down the system, minimizing process interruption .
Redundancy Support – The module works with both non-redundant and redundant IOTA configurations for enhanced system availability .
Fast Response Time – The ≤5 ms response time enables reliable capture of high-speed digital events and ensures timely control action .
Industrial-Grade Construction – The robust design with conformal coating withstands demanding conditions and ensures long-term reliability .
Comprehensive Diagnostics – Built-in diagnostics with LED status indicators simplify troubleshooting and reduce maintenance time .
Applications
The Honeywell CC-TAIN11 excels in oil and gas, chemical processing, power generation, and pharmaceutical manufacturing. It is ideal for monitoring valve positions, pump status, limit switches, and proximity sensors in Experion PKS-based DCS environments.
