Honeywell CC-TAIM01 | 64-Channel Analog Input MUX Module

Overview:

The Honeywell CC-TAIM01 (part number 51305959-175) is a high-density, low-level analog input multiplexer (MUX) module from the IOTA Series. Designed for industrial automation and process control systems, it efficiently interfaces with a wide range of sensors and transducers. With the ability to handle up to 64 isolated analog inputs, it offers exceptional flexibility and performance for real-time data acquisition.

Key Features and Specifications:

High Channel Density: Supports 64 fully isolated analog inputs, ensuring compact and efficient signal acquisition for complex systems.
Fast Data Acquisition: Capable of scanning up to 64 channels per second, ensuring rapid responsiveness for process control applications.
Low Noise Design: Engineered to minimize electrical interference, providing clean and accurate signal measurements.
Reliable Isolation: Provides channel-to-channel and channel-to-system isolation, enhancing safety and preventing crosstalk.
Modular Integration: Fully compatible with Honeywell’s IOta and Series C platforms, offering seamless integration into industrial automation systems.
Industrial Durability: Built to operate continuously in harsh industrial environments, ensuring long-term reliability.

Technical Specifications:

Specification	Value
Model	CC-TAIM01
Part Number	51305959-175
Input Channels	64 fully isolated analog inputs
Input Type	Low-level analog signals
Scan Rate	Up to 64 channels per second
Isolation	Channel-to-channel, channel-to-system
Input Voltage Range	0-10V or 0-20mA
ADC Resolution	16-bit
Scan Rate per Channel	1 kHz
Accuracy	±0.1% of full scale
Input Impedance (Voltage)	>1 MΩ
Input Impedance (Current)	2500 Ω
Isolation Voltage	1500V RMS
Operating Temperature	0°C to 60°C
Power Supply	24VDC ±10%, 50mA
Dimensions	100 mm x 75 mm x 22.5 mm
Mounting	DIN rail mountable
Weight	0.56 kg
Warranty	12 months
Condition	Brand new
Country of Origin	USA

Applications:

The Honeywell CC-TAIM01 is ideal for use in various industrial sectors, including:

Process Control: Ensures real-time measurement and control of industrial processes, such as temperature, pressure, and flow.
Manufacturing: Integrates seamlessly into automation systems, improving the monitoring of production lines and equipment.
Data Acquisition: Collects data from a wide range of sensors, providing accurate and fast measurements for analysis and reporting.
Environmental Monitoring: Monitors critical environmental parameters in industries like water treatment, power generation, and chemical processing.

Advantages:

High Flexibility: The ability to handle up to 64 isolated analog inputs allows for integration into high-density, complex measurement systems.
Enhanced Safety: The isolation between channels and the system prevents electrical faults, ensuring safe operation in industrial environments.
Easy Integration: Designed for compatibility with Honeywell’s IOta and Series C platforms, enabling effortless system integration and scalability.
Fast Response Time: With a scan rate of 64 channels per second, the module ensures rapid and accurate data collection for real-time process control.
