Honeywell CC-TAID01 16-Channel Differential Analog Input Terminal Assembly

Overview

The Honeywell CC-TAID01 is a 16-channel differential analog input terminal assembly designed for the Experion PKS C-Series distributed control system. This module efficiently collects analog signals from sensors and transmitters, converting them into digital signals for processing. By providing high-precision input, it enhances the accuracy of control systems in demanding industrial environments.

Key Specifications

Key Features

• 16-Channel Input: The CC-TAID01 provides 16 differential analog inputs, allowing the module to handle multiple sensor signals simultaneously. This makes it suitable for complex industrial control systems.
• High Accuracy: Achieving an accuracy of ±0.1% of full scale, this module ensures that collected data is precise and reliable, minimizing the risk of errors.
• Configurable Sampling Rate: You can adjust the sampling rate based on the specific needs of your application, offering more flexibility.
• High Impedance Input: This feature makes the module compatible with various analog sensors and transmitters, ensuring seamless integration into your existing setup.
• Strong Isolation: The module includes 500 Vrms isolation, which protects the input circuitry from electrical noise and prevents potential damage from surges.
• DIN Rail Mounting: Designed for easy installation, the module mounts securely on standard DIN rails, simplifying system integration.

Environmental Conditions

The Honeywell CC-TAID01 performs reliably in harsh industrial environments, ensuring durability under the following conditions:

• Operating Temperature: The module functions within a temperature range of -40°C to +70°C, making it suitable for extreme environmental conditions.
• Humidity: It operates efficiently in areas with 5-95% relative humidity, non-condensing, adding versatility for different industrial settings.

Applications

The Honeywell CC-TAID01 serves a variety of applications, including:

• Process Control: It accurately collects analog signals, such as temperature, pressure, and flow rate, essential for monitoring and controlling industrial processes.
• Industrial Automation: The module’s precise data collection ensures reliable control over devices like actuators and motors.
• Energy Management: It allows the monitoring of power consumption, making it ideal for energy management systems in industrial facilities.

Benefits

• Improved Signal Integrity: With its high accuracy and strong isolation, the module ensures precise data collection while minimizing the risk of interference and signal loss.
• Flexible Operation: Its user-configurable sampling rate and high impedance input make it adaptable to a wide range of industrial applications.
• Reliable Performance: Built to withstand extreme temperatures and humidity, the CC-TAID01 ensures long-term reliability, even in harsh environments.
