Honeywell CC-SDOR01 Digital Output Relay Extension

Overview

The Honeywell CC-SDOR01 is a high-performance digital output relay extension board designed specifically for Honeywell Experion PKS Distributed Control Systems (DCS). This extension board significantly expands the capabilities of the base I/O module by adding additional relay outputs. It ensures enhanced control and communication, making it an ideal solution for industrial applications requiring high reliability and precision.

Key Features

Enhanced Relay Outputs: The CC-SDOR01 extends the relay output capacity of the Experion PKS system, offering up to 32 isolated contacts for greater flexibility in various industrial processes.
High Durability: Built for longevity, the board provides a high contact rating of 3A at 250 VAC, ensuring reliable performance under heavy load conditions.
Fast Switching: With a switching time of just 10 ms, the CC-SDOR01 ensures swift and efficient control, reducing response time and increasing overall system performance.
Long Life Expectancy: Designed to endure, the module boasts an impressive life expectancy of 100,000,000 operations, making it a cost-effective choice for long-term industrial use.
Strong Electrical Isolation: The CC-SDOR01 features 2500 VAC isolation voltage, offering protection from electrical faults and ensuring safe operation in demanding environments.
Environmental Protection: This module performs reliably in a range of conditions, operating in temperatures from -40°C to 85°C and tolerating 0 to 95% non-condensing humidity.
Easy Installation: The CC-SDOR01 mounts easily on a DIN rail, making installation straightforward and convenient, reducing setup time and complexity.

Technical Specifications

Parameter	Specification
Model Number	CC-SDOR01
Type	Digital Output Relay Board
Mounting Type	DIN Rail
Input Voltage	24 VDC
Output Type	32 Isolated Contacts (Form A or Form B)
Contact Rating	3A at 250 VAC
Switching Time	10 ms
Life Expectancy	100,000,000 operations
Isolation Voltage	2500 VAC
Operating Temperature	-40°C to 85°C
Humidity	0% to 95% non-condensing

Why Choose the Honeywell CC-SDOR01?

The Honeywell CC-SDOR01 provides industrial applications with enhanced relay output capacity and exceptional reliability. With its fast switching speed and long operational lifespan, this module ensures efficient and continuous operation. Its high isolation voltage and durable design make it a secure and reliable choice for industrial control systems. Additionally, its compact design with DIN rail mounting simplifies installation, saving time and resources in system setup.
