Honeywell CC-PDIL01 24V Digital Input Module

Overview

The Honeywell CC-PDIL01 is a 24V digital input module within the Honeywell Experion Series C I/O system. It is designed to efficiently handle 24V DC signals, offering exceptional functionality and reliability for industrial applications. With features like redundant configurations, galvanic isolation, and open-wire detection, this module ensures accurate control and operation in demanding environments.

Key Features

24V DC Input: Accepts 24V DC signals as discrete inputs, ideal for industrial environments.
Input Channels: Provides 32 input channels to support multiple field devices.
Redundancy: Optionally supports redundant configurations for increased reliability.
Internal or External Field Power Selection: Allows flexible power options to match specific application requirements.
On-board Excitation Power: No need for external marshalling power, simplifying installation.
Galvanic Isolation: Ensures 1500 VAC RMS or +1500 VDC isolation for protection against electrical faults.
Open-Wire Detection: Alerts for open field wires to prevent incorrect control actions.
Direct/Reverse Input Indication: Provides clear input status, enabling easy troubleshooting.
Non-incendive Field Power: Supplies safe, non-incendive field power for hazardous locations.

Technical Specifications

Parameter	Details
Model Number	CC-PDIL01
Product Type	24V Digital Input Module
Input Channels	32
Input Voltage Range	18-30 VDC
Input Impedance	4.2 kΩ
Galvanic Isolation	1500 VAC RMS or +1500 VDC
Isolation Technique	Optical (in 10M)
ON Sense Voltage/Current	>13 VDC or >3 mA
OFF Sense Voltage/Current	<5 VDC or <1.2 mA
Delay (Input Filter & Isolation)	5 ms +20%
Field Resistance for Guaranteed ON	<300 Ω @ 15 VDC
Field Resistance for Guaranteed OFF	>30 kΩ @ 30 VDC
Operating Temperature Range	-40°C to +70°C
Storage Temperature Range	-40°C to +85°C
Relative Humidity	5% to 95% (non-condensing)
Power Requirements	24VDC, 500 mA
Power Consumption	12W
Vibration	0.5g RMS, 5 Hz to 500 Hz
Shock Resistance	5g, 20 ms
Ingress Protection	IP66
Dimensions	9″ x 6″ x 1.2″
Weight	3 kg

Applications

The Honeywell is ideal for industrial control systems requiring reliable and robust digital inputs. Its applications include:

Process Control Systems: Used in applications like temperature, pressure, and flow control.
Data Acquisition Systems: Collect and process data from field devices with precision.
SCADA Systems: Integrate seamlessly for centralized monitoring and control.
Industrial Automation: Ideal for automation systems requiring precise input signal handling and high reliability.

Benefits

Enhanced Reliability: With redundant configurations and galvanic isolation, this module ensures safe, continuous operation.
Versatile Power Options: The internal or external field power selection offers flexibility in different industrial setups.
Improved Safety: Non-incendive power and open-wire detection features ensure operational safety in hazardous environments.
Easy Installation: The on-board excitation power eliminates the need for marshalling power, simplifying wiring.
Durable in Harsh Environments: Designed to withstand extreme temperatures, vibration, and shock for demanding industrial environments.
