Honeywell 900H03-001 8-Channel Digital Output Module

Overview

The Honeywell 900H03-001 is an 8-channel digital output module that works with 120/240 VAC to control high-power industrial devices. As part of the Honeywell HC900 Controller Series, this module is designed for demanding applications, such as process control, machine automation, and building systems. It delivers reliable performance with high current outputs and built-in diagnostic features to ensure system protection and longevity.

Key Features

• 8 Independent Channels: Each of the 8 channels provides high current output, enabling the control of multiple devices simultaneously.
• High Current Output: The module offers a maximum output of 8A per channel, making it suitable for high-power control applications.
• Isolated Outputs: All outputs are electrically isolated from each other, which prevents interference, enhances signal accuracy, and protects equipment from cross-channel issues.
• Built-In Diagnostics: The module continuously monitors its outputs for faults. Features like overcurrent protection and short-circuit detection ensure early identification of electrical problems, preventing damage to connected devices.
• Space-Efficient Design: With its compact form, the 900H03-001 fits easily into industrial control panels, optimizing space without sacrificing functionality.

Applications

• Process Control: The module is ideal for precise control in manufacturing processes, ensuring smooth operation in real-time systems.
• Machine Automation: Use it to automate machinery operations, from simple on/off controls to complex automated workflows.
• Building Automation: The 900H03-001 integrates seamlessly with HVAC, lighting, and other systems in commercial and industrial buildings.
• Energy Management: It efficiently controls energy-consuming devices, helping to optimize power usage and reduce costs.
• Transportation: This module supports control systems in transportation infrastructure, ensuring high reliability and efficient system management.

Technical Specifications

Dimensions and Weight

• Dimensions: Designed to fit standard control panel configurations, allowing for easy installation.
• Weight: Lightweight for quick handling and installation.

Country of Origin

• Made in the USA
