The Honeywell 900B08-0202 Analog Output Module offers high precision and reliability, making it ideal for a wide range of industrial automation applications. It provides 8 isolated analog outputs, each with a selectable range of 0 to 20mA, ensuring precise control. Moreover, with its advanced galvanic isolation and diagnostic capabilities, this module supports seamless integration and smooth operation within complex automation networks.
Key Features and Specifications of the 900B08-0202
The Honeywell 900B08-0202 module combines accuracy, flexibility, and robust performance. It delivers the following key specifications:
| Specification | Details |
|---|---|
| Outputs per module | 8 outputs, isolated in 2 groups of 4 (1-4, 5-8) |
| Current Range | 0 to 21.0 mA (selectable range) |
| Load Resistance | 750 ohms max |
| Galvanic Isolation | 500 VDC (group to group, and from logic) |
| Accuracy | 0.1% full scale at reference conditions |
| Modules per rack | 4 modules max when powered from internal 24V backplane |
| Minimum Current Sensing | > 0.5 mA per output |
| Calibration Data | Stored in non-volatile memory, with automatic rejection of bad versions |
| Diagnostics | Monitors Factory Calibration, Field Calibration, and Configuration |
| Output Verification | Feedback to controller indicating output current flow |
| D/A Resolution | 13+ bits (1 part in 13,332) |
| Power Supply Loading | 5V: 225 mA max, 24V: 350 mA max |
| Terminal Block | 36 Position, Euro-style (Model 900TCK0001) |
The 900B08-0202 module excels in real-time data output management, ensuring minimal current sensing errors. Additionally, its galvanic isolation prevents voltage interference, while providing system stability. This makes the module highly reliable for critical control tasks, and it continuously meets the demanding needs of modern industrial systems.
Applications of the 900B08-0202 Analog Output Module
The Honeywell 900B08-0202 module is widely used in industrial automation, process control, and machinery applications. It is designed to provide precise analog control signals, ensuring that devices such as controllers, actuators, and sensors operate efficiently. As a result, you can count on this module to maintain high system uptime and performance, even in complex environments.
Why Choose the Honeywell 900B08-0202 Module?
Choose the Honeywell 900B08-0202 Analog Output Module for its exceptional accuracy and high-performance capabilities. Thanks to its compact form factor and versatile functionality, it integrates easily into various automation systems. Furthermore, the module’s non-volatile calibration memory ensures consistent performance over time, while its diagnostic features allow for proactive maintenance and monitoring.
