Honeywell 8U-TAIXA1 Analog Input I/O Module

Overview

The Honeywell 8U-TAIXA1 Analog Input I/O Module is a key component of the Honeywell Experion Process Knowledge System (PKS). It is designed to interface with single-ended analog input modules, providing a seamless connection to the Series 8 controllers. This module simplifies installation and configuration, ensuring efficient integration into automation systems.

Built for precision and reliability, the 8U-TAIXA1 module supports a wide range of industrial applications, from process control to testing and data acquisition.

Key Features

Analog Input Channels: Offers 40 single-ended analog input channels, enabling versatile signal management.
Current Input: Supports 4-20mA current input, widely used in industrial sensor systems.
HART Sensor Support: Compatible with HART-enabled sensors for improved monitoring and diagnostics.
High Precision: Provides high accuracy, ensuring reliable data for critical applications.
Wide Temperature Range: Operates effectively across a broad temperature range, making it suitable for various environments.
Environmental Protection: Meets NEMA 4/42 and IP00/07 standards for protection against dust and water.
Easy Installation: Designed for simple installation and configuration, minimizing setup time.

Applications

Process Control: Ideal for managing analog signals in industrial automation systems.
Machine Control: Provides reliable analog input for machines and automation equipment.
Robotics: Supports precise control of robotic systems by integrating with various sensors.
Testing and Measurement: Ensures accurate data acquisition in testing environments.
Data Acquisition: Collects vital process data for analysis and monitoring.

Technical Specifications

Parameter	Specification
Model Number	8U-TAIXA1
Number of Channels	40
Input Type	Single-ended analog current
Input Range	4-20mA
Accuracy	±2.4% full scale
Resolution	12 bits
Update Rate	250 milliseconds
Power Input	24 VDC
Power Consumption	5W
Operating Temperature Range	-40°C to +70°C
Relative Humidity	0% to 98% (non-condensing)
Protection Rating	NEMA 4/42, IP00/07
Dimensions	178 x 102 x 40 mm
Weight	0.8 kg

Additional Information

Category: Analog Input I/O Module
Model: 8U-TAIXA1
Brand: Honeywell
Applications: Process control, machine control, robotics, testing, and data acquisition.

The Honeywell 8U-TAIXA1 module offers robust performance with high precision and easy integration into industrial automation systems. Its wide temperature range and environmental protection make it a reliable choice for various applications.
