Honeywell 8U-PAOHA1 Process Analog Output Module

The Honeywell 8U-PAOHA1 is a high-performance Series 8 Process Analog Output Module, designed to deliver reliable and precise analog output for diverse industrial applications. With a wide range of configurable output options, it is ideal for industries such as process control, manufacturing, and power generation.

Key Features:

High Accuracy: Offers precise output with an accuracy of ±0.25% of full scale, ensuring reliable control in demanding systems.
Versatile Output Types: Supports multiple output types, including voltage, current, and frequency, providing flexibility for various applications.
Wide Output Range: Capable of delivering output from -10 to +10 V, 0 to 20 mA, and 4 to 20 mA, meeting the needs of a wide range of devices.
Output Monitoring: Provides the ability to monitor both voltage and current for each channel, ensuring accurate and stable performance.
Advanced Diagnostics: Easily diagnose and troubleshoot module issues, minimizing downtime and enhancing system reliability.
Electrical Isolation: The module provides 2500V isolation between input and output circuits, ensuring safety and protection against electrical faults.
Durability: Built to withstand vibration and shock with a 5 g peak at 20 to 500 Hz and 30 g peak for 11 ms, making it suitable for harsh industrial environments.

Technical Specifications:

Parameter	Specification
Model Number	8U-PAOHA1
Product Type	Process Analog Output Module
Accuracy	±0.25% of full scale
Resolution	16 bits
Output Range	-10V to +10V, 0 to 20 mA, 4 to 20 mA
Output Type	Voltage, Current, Frequency
Isolation	2500V isolation between input and output
Power Consumption	20 mA
Operating Temperature	-40°C to +85°C (-40°F to +185°F)
Storage Temperature	-40°C to +85°C (-40°F to +185°F)
Humidity	5% to 95% non-condensing
Vibration Resistance	5 g peak at 20 to 500 Hz
Shock Resistance	30 g peak for 11 ms

Applications:

Process Control: For industrial automation and control systems.
Manufacturing: To integrate with manufacturing systems that require analog output.
Power Generation: For reliable signal control in power generation plants.
Building Automation: Ideal for applications requiring high accuracy and reliable output signals.

The Honeywell 8U-PAOHA1 is engineered to deliver high stability and precision in industrial environments, making it a trusted choice for applications requiring consistent analog signals. Its robust design ensures reliable operation, even in harsh conditions, providing an effective solution for demanding industries.
