Honeywell 8C-TDILA1 Digital Input Pulse Accumulation Module

The Honeywell 8C-TDILA1 51307141-175 is a high-performance digital input pulse accumulation module, specifically designed for use in industrial automation systems. As part of the Honeywell Series 8 family of programmable logic controllers (PLCs), it ensures accurate data acquisition and processing from field devices.

Technical Specifications

Key Features

• Pulse Accumulation: The 8C-TDILA1 module is capable of counting pulses at rates of up to 100 kHz, ensuring rapid and accurate signal processing.
• High Input Impedance: With an impressive 10 MΩ input impedance, it connects easily to high-impedance sensors such as dry contact switches and optical encoders.
• Parallel Connection: To enhance flexibility, users can connect two 8C-TDILA1 modules in parallel, effectively doubling the input channels for greater system capacity.
• Advanced Diagnostics: The module offers robust diagnostics, including input range checking, broken wire detection, and sensor short-circuit detection, ensuring reliable performance in all conditions.

Applications

• Speed Measurement: The 8C-TDILA1 is ideal for applications requiring precise speed measurements, particularly in fast-paced industrial environments.
• Position Measurement: It excels at tracking position, making it an essential tool in automated systems where accuracy is critical.
• Counting Events: With its fast pulse accumulation, it is perfect for counting events, thereby enhancing the reliability of automated processes.
• Machine Status Monitoring: The module helps monitor machine status, enabling continuous performance checks and improving operational efficiency.
