HONEYWELL 8C-TDIL51 51306969-175 Digital Input Module

Function

The HONEYWELL 8C-TDIL51 Digital Input Module processes 24VDC signals as discrete inputs, ensuring reliable communication between the field and the system.

Notable Features

Comprehensive Diagnostics: Offers extensive internal diagnostics for enhanced data integrity.
Redundancy Option: Supports optional redundancy for critical applications.
Field Power Selection: Allows for internal or external field power configuration.
Non-Incendive Field Power Supply: Capable of supplying non-incendive field power (for internal power only).
Galvanic Isolation: Provides system-to-field galvanic isolation with external user-supplied power.

Detail Specifications

Parameter	Specification
Input/Output Model	8C-PDIL51 – 24V Digital Input, Coated
IOTA Model	8C-TDIL51 Non-Redundant, Coated 9”
Input Channels	32
Galvanic Isolation	1000 VAC RMS (System-to-Field) with user-supplied power
Isolation Technique	Optical (in IOM)
DI Power Voltage Range	18 to 30 VDC (for user-supplied field power)
ON Sense Voltage/Current	≥ 13 VDC or ≥ 3 mA
OFF Sense Voltage/Current	≤ 5 VDC or ≤ 1.2 mA
Input Impedance	4.2 KΩ
Absolute Delay	5 ms ± 20%

This digital input module provides robust performance, safety, and flexibility for industrial control systems. For more details or to place an order, contact us directly!
