Honeywell 51109684-100 High-Efficiency Power Supply

Overview

The Honeywell 51109684-100 is a high-performance power supply module designed for industrial automation systems. It provides stable DC power to critical control components, ensuring continuous, reliable operation in demanding environments. This module is part of the Honeywell Universal Control Network (UCN) and is frequently used in process control applications. With robust protection features, it ensures that industrial equipment runs smoothly, even under challenging conditions.

Key Features

High Efficiency: With an efficiency of over 90% at full load, the 51109684-100 minimizes energy loss and reduces operational costs.
Wide Input Voltage Range: Supports input voltages from 85-264 VAC or 120-370 V DC, making it suitable for various power sources.
Stable 24V DC Output: Provides a stable 24V DC output with +1% accuracy, essential for powering control systems.
Built-in Protection: Equipped with overvoltage, overload, short-circuit, and overtemperature protection to safeguard connected equipment.
Redundant Power Configuration: Supports redundancy to ensure higher system reliability in mission-critical applications.
Compact Design: DIN-rail mounted, enabling quick and easy integration into existing setups with minimal space requirements.
Low Noise Operation: With noise levels below 50 dB, this power supply ensures stable performance without electromagnetic interference.

Specifications

Parameter	Details
Model Number	51109684-100
Input Voltage Range	85-264 VAC (47-63 Hz) or 120-370 V DC
Output Voltage	24 VDC (+1% accuracy)
Output Current	10 A continuous, 13 A peak (5 sec)
Power Rating	240 W
Efficiency	>90% at full load
Noise Level	<50 dB
Operating Temperature	-40°C to +70°C (-40°F to +158°F)
MTBF (Mean Time Between Failures)	>100,000 hours
Protection Features	Overload, overvoltage, short-circuit, overtemperature
Mounting Type	DIN-rail mountable
Weight	500g (1.1 lbs)

Applications

The Honeywell 51109684-100 is ideal for powering critical components across a variety of industrial applications:

DCS Controllers: Powers Honeywell Experion® controllers and I/O modules for reliable system control.
Network Devices: Powers industrial network switches and devices, ensuring stable communication.
Security and Surveillance: Supplies power to security systems, supporting operations in sensitive environments.
HVAC Control Systems: Provides consistent power to HVAC control systems in large facilities.
Process Control: Used extensively in industries such as oil and gas, water treatment, and manufacturing for process control.
Industrial Automation: Powers essential equipment in automated systems, ensuring seamless operation.

Benefits

Uninterrupted Power Supply: Guarantees continuous power delivery for critical systems in industrial environments.
High-Performance Design: Delivers robust, stable power with high efficiency and minimal noise.
Enhanced Reliability: Features built-in protections and redundancy support for increased system resilience.
Space-Saving: The compact DIN-rail mounted design allows for easy integration into tight spaces.
