Honeywell 10208/2/1 Relay Output Module

The Honeywell 10208/2/1 Relay Output Module delivers exceptional performance for industrial automation systems. It features 10 output channels, each capable of handling up to 2A of current. As a result, this module can manage multiple electrical loads with high precision. Moreover, its compact design, combined with durable contact materials, ensures long-term reliability, even in demanding applications. Additionally, its low power consumption reduces system load, making it an energy-efficient solution. The 10208/2/1 integrates seamlessly into standard rack systems, offering reliable switching for machine control and process automation.

Key Features of the Honeywell 10208/2/1 Relay Output Module

Model: Honeywell 10208/2/1
Type: Relay Output Module
Manufacturer: Honeywell
Output Channels: 10 channels, allowing control of multiple electrical loads
Output Type: Relay contact, providing precise and dependable switching
Maximum Current per Channel: 2A, ensuring optimal performance
Maximum Voltage: 30 VAC / 36 VDC
Maximum Switched Power: 100 W / 1000 VA
Contact Material: Gold-flush silver-cadmium oxide, ensuring durability and long life
Power Supply:
- 5VDC: 25 mA
- 24VDC: 120 mA
Space Requirements: 4 TE, 3 HE (equivalent to 4 HP, 3U)
Weight: 0.57 lbs (0.26 kg)

The Honeywell 10208/2/1 is engineered to meet the needs of high-performance industrial environments. Thanks to its robust relay contacts, it offers excellent durability, making it suitable for environments with frequent switching cycles. Furthermore, its compact size ensures that it can be installed in tight spaces, saving valuable rack space.

Technical Specifications

Parameter	Value
Model	Honeywell 10208/2/1
Type	Relay Output Module
Output Channels	10 Channels
Output Type	Relay Contact
Maximum Current	2A per Channel
Maximum Voltage	30 VAC / 36 VDC
Maximum Switched Power	100 W / 1000 VA
Contact Material	Gold-flush silver-cadmium oxide
Power Supply (5VDC)	25 mA
Power Supply (24VDC)	120 mA
Space Requirements	4 TE, 3 HE (4 HP, 3U)
Weight	0.57 lbs (0.26 kg)

Application

The Honeywell 10208/2/1 Relay Output Module is ideal for various industrial automation applications, such as machine control and process automation. It ensures reliable and accurate electrical load control across multiple channels. Furthermore, it excels in environments that require frequent switching, offering excellent durability and performance. Its compact form factor makes it easy to install in standard rack systems, saving space without compromising on power
