Honeywell 10006/2/1-340092 Diagnostic and Battery Module

Overview of the Honeywell 10006/2/1-340092 Diagnostic and Battery Module

The Honeywell 10006/2/1-340092 is a highly efficient Diagnostic and Battery Module (DBM), designed for use with Honeywell Experion PKS and Experion LX systems. This essential component ensures reliable power supply and stores diagnostic data for seamless system monitoring and fault detection. It serves as a low-cost solution for maintaining system integrity and improving performance in industrial environments.

Key Features of the 10006/2/1-340092 DBM

Manufacturer: Honeywell
Product Type: Diagnostic and Battery Module (DBM)
Model Number: 10006/2/1-340092
Approvals: CE, TÜV, UL Certified
Software Version: >= 2.90
Space Requirements: 8 TE, 3 HE (8 HP, 3U)
Time Drift: Less than 1 second per day
Power Requirements: 5 VDC, 300 mA
Ripple Content: < 50 mV peak-to-peak
Backup Capacity: 0.5 Ah

The Honeywell 10006/2/1-340092 DBM plays a vital role in the Experion PKS and Experion LX systems, offering both power backup and diagnostic functions. It ensures the system remains functional even in the event of power fluctuations, making it indispensable for critical industrial operations.

Technical Specifications

Parameter	Value
Manufacturer	Honeywell
Product Type	Diagnostic and Battery Module (DBM)
Model Number	10006/2/1-340092
Input Voltage	120 VAC or 240 VAC
Output Voltage	12 VDC
Output Current	20 A
Battery Capacity	12 Ah
Operating Temperature	-40°C to +85°C (-40°F to +185°F)
Storage Temperature	-40°C to +85°C (-40°F to +185°F)
Humidity Range	5% to 95% (non-condensing)
Vibration Resistance	5 g peak, 20 to 500 Hz
Shock Resistance	30 g peak for 11 ms
Backup Capacity	0.5 Ah

Performance and Reliability

The Honeywell 10006/2/1-340092 is built to deliver outstanding reliability and performance. It supports high-frequency operations with excellent time drift of less than 1 second per day. The module ensures minimal ripple with a ripple content of less than 50 mV peak-to-peak, which is critical for sensitive systems requiring precise power control.

This module is designed to operate across a wide range of temperatures, from -40°C to +85°C, making it suitable for harsh industrial environments. Additionally, it performs effectively under extreme conditions, handling up to 5 g peak vibration and 30 g peak shock for up to 11 milliseconds.

Protection and Diagnostics

The 10006/2/1-340092 DBM not only provides essential power backup but also stores diagnostic information to monitor the health of your Experion PKS and Experion LX systems. It plays an integral role in fault detection, protecting your system from potential damage and minimizing downtime.

Easy Installation and Maintenance

Designed for ease of use, the Honeywell 10006/2/1-340092 module is straightforward to install and maintain. It is compatible with various systems, enhancing operational uptime and system robustness. The backup capacity of 0.5 Ah ensures reliable operation during power disruptions, providing users with peace of mind.

Ideal Applications

The Honeywell 10006/2/1-340092 Diagnostic and Battery Module is ideal for industries requiring high availability and continuous system monitoring. It is commonly used in automation systems, power distribution networks, and other mission-critical industrial applications.
