HIMA B5233-2 Central Assembly Kit

Product Overview

The HIMA B5233-2 redundant central module delivers reliable performance for safety and control systems. It combines central units, redundant power supplies, and monitoring features in one compact design. As part of the HIQuad platform, it guarantees continuous operation in critical industrial environments.

High Reliability with Redundant Power Supply

The B5233-2 supports critical applications that require maximum uptime. It operates with three F 7126 power supply modules in parallel. As a result, the system continues to run even if one module fails. In addition, the design supports up to 18 A total current, which meets the power demands of large-scale automation systems.

Integrated Monitoring and Protection

The module not only supplies power but also safeguards the system. It includes:

Z 6012 fan module with fan and fuse monitoring
Z 6011 and Z 6013 modules for decoupling and fusing
F 7131 power monitoring for supply supervision
Floating NO/NC contacts for alarms and signaling

Therefore, operators can detect problems quickly and maintain stable system performance.

Flexible Communication Options

The B5233-2 adapts easily to different communication needs. For example, users can expand the system with:

F 8625 Ethernet modules for networking
F 8626 Profibus-DP modules for fieldbus integration
F 8621A coprocessor modules for extra processing power

Consequently, the module remains suitable for a wide range of industrial automation projects.

Efficient I/O Integration

The B5233-2 connects seamlessly with B 9302 I/O racks and B 9361 power supplies. Moreover, it supports dual I/O buses with watchdog (WD) supervision. In fact, this structure ensures safe data transfer and secure communication between the central rack and I/O modules.
