GE QPI-2D101-S2P QuickPanel Operator Interface

The QPI-2D101-S2P from GE functions as a QuickPanel operator interface for industrial HMI applications. It provides a centralized touchscreen display for system monitoring and control operations. This unit delivers clear visualization of process data and alarm conditions. Operators depend on its intuitive interface for efficient plant floor management.

Technical Specifications & Hardware Details

Specification	Detail
Manufacturer	GE
Model Number	QPI-2D101-S2P
Category	Operator Interface / QuickPanel
Display Size	10.4 inches diagonal
Display Type	Standard color LCD
Input Voltage	24 VDC
Weight	Approximately 3.2 kg (7.05 lbs)
Dimensions (H x W x D)	11.0 in x 8.5 in x 2.5 in (279 mm x 216 mm x 63 mm)
Communication Ports	RS-232, RS-422, RS-485, Ethernet
Component Count	Integrated unit with touchscreen, processor, and memory
Energy Storage	Battery-backed real-time clock

Display Specifications and Visual Performance

The QPI-2D101-S2P features a 10.4-inch standard color LCD for clear process visualization. Its backlit display provides consistent visibility across varying ambient light conditions. You can configure screen layouts to show trends, alarms, and control elements simultaneously. Furthermore, the touchscreen interface supports intuitive navigation through application screens. This responsive interface reduces operator training requirements significantly.

Physical Construction and Environmental Ratings

This operator interface features a rugged construction suited for industrial environments. Its front panel meets NEMA 4 and IP65 ratings for washdown applications. The QPI-2D101-S2P mounts directly into standard panel cutouts using included hardware. You can install this unit without special tools or complex mounting procedures. The compact depth allows installation in shallow enclosures.

Communication Capabilities and System Integration

The unit supports multiple communication protocols for connecting to various controllers. Its integrated Ethernet port enables network connectivity for data logging and remote access. The QPI-2D101-S2P communicates with GE PLCs and third-party controllers seamlessly. For similar industrial applications, static trip units and protective relays use comparable communication principles. However, this operator interface specifically addresses HMI requirements within industrial automation systems. Facilities rely on it for centralized monitoring and control of manufacturing processes.
