GE IS410STAIS2A Mark VI Analog Input Board

The GE IS410STAIS2A board converts analog field signals for the Mark VI system. This analog input board accepts current and voltage inputs from field transmitters. It provides accurate process data for turbine monitoring and control. The board delivers high reliability in harsh industrial environments.

Technical Specifications of GE IS410STAIS2A

Component Count and Board Construction

The GE IS410STAIS2A board contains over 180 discrete components on its surface. You will find multiple operational amplifiers for signal conditioning. Furthermore, the board includes precision voltage reference circuits for accuracy. The assembly also features opto-isolators for channel-to-channel isolation.

Interfaces, Energy Storage, and Signal Processing

The GE IS410STAIS2A provides a front-face terminal block for field wiring. Moreover, the board uses capacitors for analog filter networks. These capacitors store minimal energy but provide critical noise rejection. Each channel includes a dedicated analog-to-digital converter for simultaneous sampling.

Functional Logic and Application Context

This Mark VI board scans all eight input channels continuously. It then transmits digital values to the main controller via the VME bus. The GE IS410STAIS2A also performs open-wire detection on 4-20 mA loops. Additionally, it applies software-configurable scaling to each input channel. Consequently, you can adapt the board to various sensor types easily.

Installation and Environmental Limits

You must power down the VME rack before inserting this analog input board. The operating temperature range spans 0°C to 60°C . Furthermore, the board provides 1500 V isolation between field and logic sides. Always verify the GE IS410STAIS2A jumper settings before initial power-up.
