GE IS200TTURH1B IS200TTURH1BAA Termination PC Board

Technical Specifications

The GE IS200TTURH1B (also IS200TTURH1BAA) serves as a passive termination PC board. This board measures 35.6 cm in length and 20.3 cm in width. It weighs approximately 1.3 kg. The unit contains 48 screw terminal blocks for field wiring. A single 50-pin ribbon cable connector links to the main controller. Additionally, the board features four LED indicators for status monitoring. The GE IS200TTURH1B IS200TTURH1BAA stores no firmware or operational data locally. It also holds zero battery-based energy storage. Instead, this board simply routes signals passively.

Parameter	Specification
Brand	General Electric (GE)
Model	GE IS200TTURH1B IS200TTURH1BAA
Category	Termination PC Board
Length	35.6 cm
Width	20.3 cm
Weight	~1.3 kg
Terminal Blocks	48 screw-type terminals
Main Interface	One 50-pin ribbon cable connector
Status Indicators	Four LED indicators
Onboard Memory	None
Energy Storage	None (passive design)

Design and Integration

This GE IS200TTURH1B IS200TTURH1BAA terminates field wiring for Mark VI turbine systems. The 48 terminals accept 12 to 24 AWG copper wires. Each terminal handles up to 5 A at 250 V AC/DC. Therefore, the board connects sensors, actuators, and interlocks safely. The ribbon cable carries signals to the main processor board. Meanwhile, the four LEDs show power and communication status. For a similar interface component, see the RMS-TSG-TZ-C on Alibaba. However, that device focuses on static trip protection, not termination.

Reliability and Installation

The GE IS200TTURH1B IS200TTURH1BAA operates from -40°C to +70°C. Its passive design eliminates any maintenance for batteries or firmware. Consequently, you achieve long-term reliability in harsh environments. The board mounts directly onto a DIN rail or backplane. Each unit meets GE’s insulation resistance standards above 100 MΩ.
