GE IS200TRLYH1B IS200TRLYH1BGF Relay Output Terminal

The GE IS200TRLYH1B IS200TRLYH1BGF Relay Output Terminal Board MK VI IS200 provides high-power relay switching for field actuators. You will find this board essential for controlling pumps, valves, and contactors. Its rugged design handles inductive loads without additional suppression components.

Dimensions, Weight, and Mechanical Layout

This relay output terminal board measures 21.5 cm in length and 16.2 cm in width. Its height reaches 4.5 cm including all relay housings. The total weight stands at 0.68 kilograms for heavy-duty DIN-rail mounting. A flame-retardant UL 94V-0 PCB provides excellent fire safety protection.

Relay Interfaces and Component Count

The GE IS200TRLYH1B IS200TRLYH1BGF Relay Output Terminal Board MK VI IS200 offers twelve independent electromechanical relay outputs. Each relay provides Form C (SPDT) contacts rated at 5 amperes. You also receive eight LED indicators for visual relay status confirmation. In total, this board contains 156 individual electronic components. These include 12 relays, 8 LED drivers, and 96 suppression diodes.

Contact Ratings and Protection Features

Each relay contact handles 5A at 250V AC or 30V DC resistive loads. The board includes built-in flyback diodes for DC inductive load protection. All relay contacts feature 4 kV isolation from the control logic. Consequently, you can switch industrial motors and solenoids directly without external contactors.

Environmental Limits and Wiring Specifications

Therefore, the operating temperature ranges from -30°C to +70°C. Storage temperatures extend from -40°C to +85°C without degradation. Each screw terminal accepts 14 to 24 AWG solid or stranded wire. Maximum terminal torque rating reaches 0.5 Nm for reliable field connections.

Below table summarizes all key technical parameters:

Parameter	Value
Manufacturer	General Electric
Series	MK VI IS200
Full Product Name	GE IS200TRLYH1B IS200TRLYH1BGF Relay Output Terminal Board MK VI IS200
Model Numbers	IS200TRLYH1B, IS200TRLYH1BGF
Length	21.5 cm
Width	16.2 cm
Height	4.5 cm
Weight	0.68 kg
PCB Flammability Rating	UL 94V-0
Mounting Type	Heavy-duty DIN-rail
Independent Relay Outputs	12
Contact Form	Form C (SPDT)
Contact Current Rating	5 A resistive
Contact Voltage Rating	250V AC / 30V DC
LED Status Indicators	8
Total Components	156
Relays	12
LED Drivers	8
Suppression Diodes	96
Inductive Load Protection	Built-in flyback diodes
Isolation Voltage	4 kV (contact to logic)
Wire Gauge Range	14 to 24 AWG
Terminal Torque	0.5 Nm max
Operating Temperature	-30°C to +70°C
Storage Temperature	-40°C to +85°C

Connectors, Cabling, and Additional Features

Two 40-pin ribbon cable headers connect to the digital output control board. A single ground terminal provides chassis earth connection for surge protection. For similar static trip system relay termination, see the RMS-TSG-TZ-C model from the same manufacturer. However, this relay output board specializes in high-power field actuation exclusively. Mean time between failures (MTBF) exceeds 120,000 hours for relay mechanical life.
