Secure Termination for Turbine Emergency Trip Circuits
The GE IS200TREAS1AED IS210TREAS1AA IS200WREAH1ABB provides a centralized connection point for all trip signals. This terminal board belongs to the Mark VI series from General Electric. It interfaces with overspeed, over-temperature, and manual trip devices. Therefore, it ensures reliable signal routing for critical turbine protection functions.
Physical Dimensions and Panel Mounting Details
This trip terminal board measures 22 cm in width, 18 cm in height, and 4 cm in depth. The GE IS200TREAS1AED weighs approximately 0.54 kg, which supports stable DIN rail mounting. Its rugged construction withstands vibration in turbine environments. Consequently, you can mount it directly inside the protection cabinet.
Connector Layout and Component Configuration
The GE IS200TREAS1AED IS210TREAS1AA IS200WREAH1ABB features three 34-pin ribbon cable headers for rack interface. It also provides twenty-four 2-pin screw terminal blocks for field wiring. This board contains twenty-four transient suppression diodes for overvoltage protection. Additionally, it includes twelve energy storage capacitors for signal filtering.
| Technical Parameter | Specification |
|---|---|
| Full Model Name | GE IS200TREAS1AED IS210TREAS1AA IS200WREAH1ABB |
| Manufacturer | General Electric (GE) |
| Series | Mark VI / Speedtronic |
| Product Category | Trip Terminal Board |
| Weight | 0.54 kg (1.19 lbs) |
| Dimensions (W x H x D) | 220 mm x 180 mm x 40 mm |
| Ribbon Cable Headers | 3 x 34-pin |
| Field Terminal Blocks | 24 x 2-pin (screw type) |
| Transient Suppression Diodes | 24 units |
| Energy Storage Capacitors | 12 units (100 µF each) |
| Total Capacitance | 1,200 µF |
| Maximum Terminal Current | 5 A per block |
| Voltage Rating | 250 VAC / 125 VDC |
| Trip Input Voltage | 24 VDC, 48 VDC, 125 VDC |
| Response Time | 10 ms typical |
| Operating Temperature | –25°C to +70°C |
Energy Storage and Protection Performance
The GE IS200TREAS1AED IS210TREAS1AA IS200WREAH1ABB stores sufficient energy for signal conditioning. Its twelve capacitors provide 1,200 µF of total capacitance. This storage filters electrical noise from trip circuits. Furthermore, the suppression diodes clamp voltage spikes, preventing false trips and protecting the rack electronics.
Role Within the Mark VI Protection System
You will typically find the GE IS200TREAS1AED IS210TREAS1AA IS200WREAH1ABB mounted near the turbine emergency trip panel. It connects to the main rack via three shielded ribbon cables. Moreover, this board supports both normally open and normally closed contact inputs. Its twenty-four channels accept wiring from overspeed probes, temperature switches, and manual trip pushbuttons.
Installation and Wiring Guidelines
Use the GE IS200TREAS1AED IS210TREAS1AA IS200WREAH1ABB as a direct replacement for older TREA or WREA revisions. Always verify the trip circuit voltage before connecting any wires. This terminal board requires no external power supply for passive signal paths. It needs no configuration jumpers or special tools. Simply secure the board with four mounting screws and connect your trip circuit wires to the appropriate terminal blocks.
