GE IS200TBCIS2C IS200TBCIS2CCD Contact Input Board

The GE IS200TBCIS2C IS200TBCIS2CCD Contact Input Board monitors dry contact and limit switch status signals. You will find this board essential for collecting field device states. Its passive design requires no external power for basic signal routing.

Dimensions, Weight, and Mechanical Layout

This contact input board measures 19.0 cm in length and 14.2 cm in width. Its height reaches 3.6 cm including all screw terminal blocks. The total weight stands at 0.52 kilograms for standard DIN-rail mounting. A fiberglass-reinforced PCB provides excellent mechanical strength and insulation.

Input Interfaces and Component Count

The GE IS200TBCIS2C IS200TBCIS2CCD Contact Input Board offers thirty-two independent screw terminal connections. Each terminal accepts dry contact inputs or 24V DC signals. You also receive thirty-two LED indicators for visual contact status monitoring. In total, this board contains 144 individual electronic components. These include 32 terminal blocks, 32 LEDs, 32 current-limiting resistors, and 48 suppression diodes.

Signal Conditioning and Protection Features

Each input path includes a 2.2k ohm series resistor for current limiting. The board also features transient suppression diodes on all signal lines. A passive RC filter removes contact bounce and high-frequency noise. Consequently, the board provides reliable contact status reading in industrial environments.

Environmental Limits and Wiring Specifications

Therefore, the operating temperature ranges from -30°C to +70°C. Storage temperatures extend from -40°C to +85°C without degradation. Each screw terminal accepts 14 to 24 AWG solid or stranded wire. Maximum terminal torque rating reaches 0.5 Nm for secure field connections.

Below table summarizes all key technical parameters:

Parameter	Value
Manufacturer	General Electric
Series	Mark VI IS200
Full Product Name	GE IS200TBCIS2C IS200TBCIS2CCD Contact Input Board
Model Numbers	IS200TBCIS2C, IS200TBCIS2CCD
Length	19.0 cm
Width	14.2 cm
Height	3.6 cm
Weight	0.52 kg
PCB Material	Fiberglass-reinforced
Mounting Type	DIN-rail
Independent Screw Terminals	32
LED Status Indicators	32
Input Signal Types	Dry contact or 24V DC
Maximum Terminal Current	2 A
Total Components	144
Terminal Blocks	32
LEDs	32
Current-Limiting Resistors	32 (2.2k ohm)
Suppression Diodes	48
Signal Protection	Transient suppression per line
Contact Debounce Filter	Passive RC per channel
Power Requirement	None (passive for routing)
Wire Gauge Range	14 to 24 AWG
Terminal Torque	0.5 Nm max
Operating Temperature	-30°C to +70°C
Storage Temperature	-40°C to +85°C

Connectors, Cabling, and Additional Features

Two 40-pin ribbon cable headers connect to the digital input control board. A single ground terminal bar provides earth connection for cable shields. For similar static trip system contact monitoring, see the RMS-TSG-TZ-C model from the same manufacturer. However, this contact input board specializes in dry contact status acquisition exclusively. Mean time between failures (MTBF) exceeds 280,000 hours due to passive construction.
