GE IS200TBCIH1B IS200TBCIH1BCD Mark VI Terminal Board Controller

The GE IS200TBCIH1B board serves as a terminal board controller for Mark VI systems. This PCB also carries the revision code IS200TBCIH1BCD . It manages field wiring termination for I/O signals. The board provides organized connection points for reliable field cabling.

Technical Specifications of GE IS200TBCIH1B IS200TBCIH1BCD

Component Count and Board Construction

This GE IS200TBCIH1B board contains over 130 discrete components on its surface. You will find multiple suppression diodes for inductive loads. Furthermore, the board includes fuse holders for output channel protection. The assembly also features LED indicators for each signal path.

Interfaces, Energy Storage, and Signal Routing

The IS200TBCIH1BCD revision provides screw terminal blocks for all field connections. Moreover, the board uses capacitors for minimal noise filtering. These capacitors store very little energy for transient suppression. Each terminal point includes a dedicated test point for troubleshooting.

Functional Logic and Application Context

This Mark VI board routes discrete signals between field devices and I/O modules. It accepts inputs from limit switches, pushbuttons, and pressure switches. The GE IS200TBCIH1B also delivers outputs to solenoids, valves, and indicator lights. Additionally, it provides common bus bars for shared power distribution. Consequently, the board simplifies field wiring and reduces installation errors.

Installation and Environmental Limits

You must isolate the 24 V DC supply before servicing this terminal board. The operating temperature range spans -30°C to +65°C . Furthermore, the board withstands 5 g vibration without connection loosening. Always verify the IS200TBCIH1BCD labeling against your wiring diagram before connection.
