GE IS200TBAOH1C IS200TBAOH1CCB Mark VI Analog Output

The IS200TBAOH1C IS200TBAOH1CCB functions as an analog output board for turbine systems. This printed circuit board belongs to the Mark VI Speedtronic series from General Electric. The IS200TBAOH1C serves as the standard version for analog signal generation. Its variant, the IS200TBAOH1CCB, includes a conformal coating for enhanced circuit protection. Both boards generate analog output signals for steam and gas turbine actuators.

Core Technical Specifications

This board provides eight analog output channels for precise actuator control. You will also find a dedicated backplane interface for high-speed data transfer. The board stores minimal energy but uses capacitors for output signal smoothing. Meanwhile, the front panel connector simplifies all field wiring connections.

Parameter	Specification
Full Model No.	IS200TBAOH1C IS200TBAOH1CCB
Manufacturer	GE Industrial Systems (General Electric)
Series	Mark VI Speedtronic
Board Category	Analog Output Printed Circuit Board
Weight	Approximately 0.28 kg
Dimensions (H x W x D)	6.0 cm x 17.5 cm x 3.0 cm
Analog Output Channels	8 channels with 14-bit resolution
Output Signal Range	4 to 20 mA or 0 to 10 VDC
Backplane Interface	VME compatible
Field Connector	Front panel terminal block
Energy Storage	Small capacitors for signal smoothing
Coating (for CCB)	Conformal coated against moisture and dust

Installation and System Integration

Install the IS200TBAOH1C IS200TBAOH1CCB into any standard VME rack slot. The board connects directly to actuators through its front panel terminals. Meanwhile, the backplane supplies power and communication to the board. Therefore, proper insertion guarantees precise analog output control.
