GE IS200STCIH1A IS200STCIH1ADD Turbine Emergency Trip

The IS200STCIH1A IS200STCIH1ADD functions as an emergency trip board for gas turbines. This printed circuit board belongs to the Mark VI Speedtronic series from General Electric. The IS200STCIH1A serves as the standard version for overspeed protection. Its variant, the IS200STCIH1ADD, includes a conformal coating for enhanced circuit durability. Both boards manage emergency shutdown functions for gas turbine safety systems.

Core Technical Specifications

This board provides one emergency trip relay channel for overspeed conditions. You will also find redundant trip circuits for fail-safe operation. The board stores minimal energy but uses capacitors for contact protection. Meanwhile, the backplane interface handles all power and data transfers.

Parameter	Specification
Full Model No.	IS200STCIH1A IS200STCIH1ADD
Manufacturer	GE Industrial Systems (General Electric)
Series	Mark VI Speedtronic
Board Category	Gas Turbine Emergency Trip Board
Weight	Approximately 0.35 kg
Dimensions (H x W x D)	6.0 cm x 23.0 cm x 3.0 cm
Emergency Trip Channels	1 primary with redundant backup
Contact Rating	10A at 250 VAC or 30 VDC
Response Time	Less than 20 milliseconds
Terminal Type	Screw terminal connectors
Backplane Interface	VME compatible
Energy Storage	Small capacitors for arc suppression
Coating (for ADD)	Conformal coated against moisture and dust

Installation and System Integration

Install the IS200STCIH1A IS200STCIH1ADD into any standard VME rack slot. The board connects directly to emergency stop relays through its terminals. Meanwhile, the backplane supplies power and communication to the board. Therefore, proper insertion ensures reliable emergency trip protection.
