The IS200STAIH1A IS200STAIH1ABB functions as an acoustic monitoring terminal board for turbines. This printed circuit board belongs to the Mark VI Speedtronic series from General Electric. The IS200STAIH1A serves as the standard version for acoustic signal acquisition. Its variant, the IS200STAIH1ABB, includes a conformal coating for enhanced circuit protection. Both boards process acoustic emission data for steam and gas turbine diagnostics.
Core Technical Specifications
This board provides two acoustic sensor input channels for monitoring tasks. You will also find built-in signal conditioning for each channel. The board stores minimal energy but uses capacitors for noise reduction. Meanwhile, the backplane interface handles all power and data transfers.
| Parameter | Specification |
|---|---|
| Full Model No. | IS200STAIH1A IS200STAIH1ABB |
| Manufacturer | GE Industrial Systems (General Electric) |
| Series | Mark VI Speedtronic |
| Board Category | Acoustic Monitoring Terminal Board |
| Weight | Approximately 0.33 kg |
| Dimensions (H x W x D) | 6.0 cm x 23.0 cm x 3.0 cm |
| Acoustic Sensor Channels | 2 differential input channels |
| Frequency Response | 10 Hz to 15 kHz range |
| Signal Conditioning | Amplification and low-pass filtering |
| Terminal Type | Screw terminal connectors |
| Backplane Interface | VME compatible |
| Energy Storage | Small capacitors for noise suppression |
| Coating (for ABB) | Conformal coated against moisture and dust |
Installation and System Integration
Install the IS200STAIH1A IS200STAIH1ABB into any standard VME rack slot. The board connects directly to acoustic sensors through its screw terminals. Meanwhile, the backplane supplies power and communication to the board. Therefore, proper insertion ensures reliable acoustic monitoring performance.
