GE IS200PSCDG1A IS200PSCDG1ABB Analog I/O Card

The IS200PSCDG1A IS200PSCDG1ABB functions as a DIN rail analog I/O terminal card. This printed circuit board belongs to the Mark VI Speedtronic series from General Electric. The IS200PSCDG1A serves as the standard version for analog signal termination. Its variant, the IS200PSCDG1ABB, includes a conformal coating for extra circuit protection. Both cards terminate analog I/O signals for steam and gas turbine controls.

Core Technical Specifications

This card provides eight analog input channels for field sensor connections. You will also find four analog output channels for actuator control. The card stores minimal energy but uses capacitors for signal conditioning. Meanwhile, the DIN rail mounting simplifies installation inside control cabinets.

Parameter	Specification
Full Model No.	IS200PSCDG1A IS200PSCDG1ABB
Manufacturer	GE Industrial Systems (General Electric)
Series	Mark VI Speedtronic
Board Category	DIN Rail Analog I/O Card
Weight	Approximately 0.32 kg
Dimensions (H x W x D)	6.0 cm x 17.5 cm x 3.5 cm
Analog Input Channels	8 channels with 16-bit resolution
Analog Output Channels	4 channels with 14-bit resolution
Input Signal Range	0 to 10 VDC or 4 to 20 mA
Output Signal Range	4 to 20 mA
Mounting Type	DIN rail compatible
Terminal Type	Screw terminal connectors
Energy Storage	Small capacitors for signal filtering
Coating (for ABB)	Conformal coated against moisture and dust

Installation and System Integration

Install the IS200PSCDG1A IS200PSCDG1ABB onto any standard DIN rail. The card connects directly to analog sensors through its screw terminals. Meanwhile, the backplane supplies power and communication to the card. Therefore, proper mounting ensures reliable analog I/O termination.
